AC output diesel power generator 1200kw with meccalte alternator
- 1200 Unit / Units per Month
- T/T
You May Like
-
china factory price 728kw china generator with KTA38-G2A
-
Best choice cheap price diesel genset engine 2500kva
-
Remote control china 1000kva generat digital control diesel generator
-
China factory direct sells best china generator price list
-
China sales good quality china 400kw diesel generator
-
60hz electrical magnetic china 410kw diesel generator with KTA19-G3
Product Details
Place of Origin | Jiangsu, China | Brand Name | Zhengchi Power(ZC Power) | |
Model Number | ZCDL-C1200 | Output Type | AC Three Phase | |
Speed | 1500RPM | Frequency | 50Hz | |
Rated Power | 1200KW generator 1200kw | Rated Voltage | 400/230V | |
Rated Current | 2160A |
Product Description
AC output diesel power generator 1200kw with meccalte alternator
Diesel Generator Specifications | ||||||||
Manufacturer: | Yangzhou Zhengchi Power Equipment Co.,Ltd. | |||||||
Model: | ZCDL-P1200 | |||||||
Prime Power: | 1200KW / 1500KVA | |||||||
Standby Power: | 1320KW / 1650KVA | |||||||
Frequency: | 50HZ | |||||||
Voltage: | 400/230V | |||||||
Phase: | 3 Phase | |||||||
P.F: | 0.8 | |||||||
Fuel: | Diesel | |||||||
Rated Current: | 2160A | |||||||
Start Method: | 24V DC Start Battery | |||||||
Accessory: | Battery, wire, exhaust pipe, muffler, damper, breaker | |||||||
Altitude: | ≤1000m | |||||||
Engine Specifications | ||||||||
Manufacturer: | USA Cummins | |||||||
Model: | KTA50GS8, 4-cycle | |||||||
Air Intake System: | Turbo, Air/Air cooling | |||||||
Fuel System: | Direct Injection | |||||||
Cylinder Arrangement: | 12 in V | |||||||
Displacement: | 45.8 L | |||||||
Bore and Stroke: | 160×190 mm | |||||||
Compression Ratio: | 13.6 | |||||||
Rated RPM: | 1500rpm | |||||||
Maximum Output Power: | 1437KW/1955HP | |||||||
Governor Type: | Electronic | |||||||
Alternator Specifications | ||||||||
Manufacturer: | Mecc Alte S.p.A (Italy) | |||||||
Model: | ECO46-1S/4 | |||||||
Rated Capacity: | 1500 KVA | |||||||
Winding: | 100% Copper Wire | |||||||
Frequency: | 50HZ | |||||||
Speed: | 1500 RPM | |||||||
Connecting Type: | 3 Phase and 4 Wires, “Y” type connecting | |||||||
Power Factor: | 0.8 | |||||||
Protection Grade: | IP23 | |||||||
Exciter Type: | Brushless, self-exciting, with AVR | |||||||
Insulation Class, Temperature Rise: | H/H | |||||||
Alternator Warranty: | 2 Year No Time Limited | |||||||
Voltage Regulation: | ≥±5% | |||||||
Control System Specifications | ||||||||
Manufacturer: | DEEP SEA ELECTRONICS PLC (UK) | |||||||
Model: | DSE6020 | |||||||
Type: | AMF Automatic Operation | |||||||
Operation: | Automatic Start and Auto Mains (Utility) Failure Control | |||||||
Alarm Protect: | Engine pre-heat, Current monitoring, Comprehensive Shutdown, Charge Failure | |||||||
Size and Weight | ||||||||
Open Type Overall Size: | 4750mm*1710mm*2300mm | |||||||
Weight: | 12500 kg | |||||||
Soundproof Type Overall Size: | 6058mm*2438mm*2896mm | |||||||
Weight: | 17500 kg |
Open Genset:
Silent Genset:
Synchronization System:
generator 1200kw Packaging: nude or plywood package
generator 1200kw Shipping: 20 days after deposit
(1) generator 1200kw Warranty time: 1 year or 1000 running hours, which occurs the first
Yangzhou Zhengchi Power Equipment Co, Ltd, locates in Yangzhou City, Jiangsu Province, which is the manufacturing centrality of generator 1200kw industrial zone in Southeast China, Zhengchi Power owns 3 subsidiary factories, one is to produce brushless alternator, second is to produce silent canopy and trailer, third is to assemble diesel generator set, registered capital with 61000000.00 RMB.
Zhengchi Power is specialized in manufacturing generator 1200kw and supplying various power products, like engine parts, controllers, ATS etc. Zhengchi Power manufactures OEM generator powered by Cummins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators.
(1) Your company is factory or Trade Company?
Answer: We are professional generator 1200kw manufacturing factory.
(2) Your diesel generator power range?
Answer: Now we mainly produce 7KW to 2400KW generator 1200kw.
(3) Which brand Electrical Generator you produce?
Answer: Now we produce USA brand generator 1200kw, Sweden Volvo Generator, Korea Doosan diesel generator, German Deutz Electrical Generator, and China local brands' generator.
(4) Where is your main market?
Answer: We mainly export generator 1200kw to Africa, Middle East, Asia, and South Korea...
