Home > Products > Others Brand Enginge > China distributor generator 60HZ by Deutz diesel engine 1500rpm
China distributor generator 60HZ by Deutz diesel engine 1500rpm
- 20000 Unit / Units per Month
- Shanghai port
- T/T
You May Like
-
Power generator with engine for 60HZ use
-
Dynamo diesel generator new products on China market
-
Diesel magnetic generator 60HZ with Deutz engine
-
Diesel magnet generator with Deutz engine 60HZ for home
-
60HZ Diesel generator powered by Deutz engine from China
-
Magnet generator with magnetic alternator for Asia
Product Details
Place of Origin | Jiangsu, China | Brand Name | ZCDL | |
Model Number | ZCDL-D93-60 | Output Type | AC Three Phase | |
Speed | 1800RPM - 60HZ | Frequency | 60HZ | |
Rated Power | 85KW / 106KVA | Rated Voltage | 440/230V | |
Rated Current | 153A |
Product Description
China distributor generator 60HZ by Deutz diesel engine 1500rpm
Diesel Generator Specifications | ||||||||
Manufacturer: | Yangzhou Zhengchi Power Equipment Co.,Ltd. | |||||||
Model: | ZCDL-D93-60 | |||||||
Prime Power: | 85KW / 106KVA | |||||||
Standby Power: | 93KW / 116KVA | |||||||
Frequency: | 60HZ | |||||||
Voltage: | 440/254V | |||||||
Phase: | 3 Phase | |||||||
P.F(COS): | 0.8 | |||||||
Fuel: | Diesel | |||||||
Rated Current: | 153A | |||||||
Start Method: | 24V DC Start Battery | |||||||
Accessory: | Battery, wire, exhaust pipe, muffler, damper, breaker | |||||||
Altitude: | ≤1000m | |||||||
Open Type Generator Size: | 2150(mm)×750(mm)×1550(mm) | |||||||
Open Type Generator Weight: | 1290KG | |||||||
Silent Type Generator Size: | 2810(mm)×1140(mm)×1830(mm) | |||||||
Silent Type Generator Weight: | 1850KG | |||||||
Engine Specifications | ||||||||
Manufacturer: | DEUTZ(DALIAN) | |||||||
Model: | BF4M1013EC, 4-cycle | |||||||
Air Intake System: | Turbo, Air/Air Cooling | |||||||
Fuel System: | Directly Injection ,Single injection Pumps | |||||||
Cylinder Arrangement: | 4 in line | |||||||
Displacement: | 4.76L | |||||||
Bore and Stroke: | 108*130 mm | |||||||
Compression Ratio: | 19.0 | |||||||
Rated RPM: | 1800rpm | |||||||
Maximum Output Power: | 111KW/151HP | |||||||
Governor Type: | Mechanical Governor | |||||||
Exhaust System | ||||||||
Exhaust Gas Flow: | 21.9m3/min | |||||||
Exhaust Temperature: | 520℃ | |||||||
Max Back Pressure: | 3kPa | |||||||
Air Intake System | ||||||||
Max Intake Restriction: | 2.5kPa | |||||||
Burning Capacity: | 7.76m3/min | |||||||
Air Flow: | 127m3 /min | |||||||
Fuel System | ||||||||
100%( Prime Power) Load: | 212 g/Kw.h | |||||||
75%(Prime Power) Load: | 213 g/Kw.h | |||||||
50%(Prime Power) Load: | 219 g/Kw.h | |||||||
100%( Prime Power) Load: | 23.4L/h | |||||||
Oil System | ||||||||
Oil Consumption: | 0.3% of Fuel Consumption | |||||||
Engine Oil Tank Capacity: | 11L | |||||||
Oil Pressure at Rated RPM: | >270kPa | |||||||
Cooling System | ||||||||
Total Coolant Capacity: | 19.7L | |||||||
Thermostat: | 83-95℃ | |||||||
Max Water Temperature: | 110℃ | |||||||
Alternator Specifications | ||||||||
Manufacturer: | Mecc Alte Alternator (Haimen) Ltd. | |||||||
Model: | ECP34-2S/4 | |||||||
Rated Capacity: | 126KVA | |||||||
Winding: | 100% Copper Wire | |||||||
Frequency: | 60HZ | |||||||
Speed: | 1800 RPM | |||||||
Connecting Type: | 3 Phase and 4 Wires, “Y” type connecting | |||||||
Power Factor: | 0.8 | |||||||
Protection Grade: | IP23 | |||||||
Exciter Type: | Brushless, self-exciting, with AVR | |||||||
Insulation Class, Temperature Rise: | H/H | |||||||
Alternator Warranty: | 2 Year No Time Limited | |||||||
Voltage Regulation: | ≥±5% | |||||||
Control System Specifications | ||||||||
Manufacturer: | DEEP SEA ELECTRONICS PLC (UK) | |||||||
Model: | DSE501K | |||||||
Type: | Manual Operation | |||||||
Operation: | Via a three position key switch with STOP(O), RUN(I) and START(II). | |||||||
Alarm Protect: | Low Oil Pressure, High Engine Temperature, Auxiliary Shutdown, Charge Failure |
China distributor generator Packaging: nude or plywood package
China distributor generator Shipping: 10 days after deposit
Yangzhou Zhengchi Power Equipment Co.,LTD ( abbreviation: ZC Power Equipment Co., Ltd.), Located in Yangzhou City, Jiangsu Province, which is the central part of manufacturing China distributor generator industrial zone in Southeast China. ZC Power is specialized in manufacturing Diesel Generating Set and supplying various power products, like engine parts, controllers, ATS etc. ZC Power manufactures OEM generator powered by Cummins, Deutz, Volvo, MTU, Doosan engines and Stamford, Leroy Somer, Mecc Alte alternators. ZC Power Genset ranges from 7KW to 2400KW, 50Hz or 60Hz frequency, with open type, silent type, trailer type and containerized type, etc. All products are manufactured in accordance with the ISO8528 production standard to assure them of best quality produced and accepted for export to the international market.
Besides manufacturing China distributor generator, we also supply various power products to meet customer one-stop solutions, such as transformers, power cables, control panel, generator spare parts, field service, etc.
ZC Power commitment is to provide power products to meet customers requirements, and create more value for users, make contributions to social development by providing power.
Open, efficiency, and cooperation are values of ZC Power. We keep an open mind, emphasize operational efficiency, advocate teamwork, and respect for professional accumulation, committed to building a professional, first-class brand in electrical products and engineering equipment.
1) Your company is factory or trade company?
Answer: We are professional China distributor generator manufacturing factory.
(2) Your diesel generator power range?
Answer: Now we mainly produce 7KW to 2400KW China distributor generator.
(3) Which brand Electrical Generator you produce?
Answer: Now we produce USA brand China distributor generator, Sweden Volvo Generator, Korea Doosan diesel generator, German Deutz Electrical Generator, and China local brands' generator.
(4) Where is your main market?
Answer: We mainly export China distributor generator to Africa, Middle East, Asia, and South Korea...
Zhengchi Power Workshop
