Dredging Hose/Suction Hose/Manufacturer

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	Deers
Model Number	Suction hoses

Dredging hose/suction hose
1.Safe and flexible to use
2.Easy to install
3.Abrasion and bending resistant

suction hose /dredging hose

Decription:

Suction Hose mostly used with thesehoses are the rubber flange/steel backing

flange and theDouble Action flange. They can be supplied in any size,and

depending on application, with 100% vacuum capability and high implosion

pressures. In some applications heavy spring steel spirals are used to prevent

the hose from kinking. Spring steel spirals absorb these peak loads without the

risk of collapsing.

Feature:

lSafe and flexible to use

lEasy to install

lAbrasion and bending resistant

Specification:

Suction hose performance index
Test project	National standard for inner wall thickness	Our product standard	National standard for external casing	Our product standard
Break strength Mpa	>120	>150	>100	>130
Elongation at break %	>400	>500	>400	>500
Akron abrasion square centimetre /1.6km	1	<0.8	1	<0.8
Shore hardness		60-66		60-66
Working temperature		-40~+60		-40~+60

ID		(Mpa) Working Pressure	(m) Length	(mm) Pipe Wall Thickness
mm	(mm) T	(Mpa) Working Pressure	(m) Length	(mm) Pipe Wall Thickness
250	±2	60mm mercury column Max vac 650mm high	1-3	31-32
300	±2		1-3	34-37
414	±2		1-3	35-37
560	±3		2-3	40-45
600	±3		2-3	40-45
700	±3		2-3	40-45
800	±4		2-3	50-52
900	±4		2-3	55-58

Inner side layout
