Long life-span flexible suction hose for dredger

FOB Price

Negotiable / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	Deers
Model Number	Suction hose

flexible suction hose
1.High quality, good service.
2.Flexible,high strength.
3.Easy to install.

flexible suction hose

Discription:

The suction hose is installed between the pump and cutter of the dredger to suck the mixture of silt and water with negative pressure.

The suitable working temperature is from -20°C to +50°C.

Thickness : the pipe wall is from 20mm to 50mm.

Construction:

Wear tube: Mainly Nature rabber mixing SBR o NBR

Tire cord: High strength polyester cord fabril.

Wire: High tensile, spring steel wire

Cover: Weather resistant EPDM, SBN o NBR

Featuress:

♦ Convinient to use

♦ Flexible

♦ High strength and abrasion resistant

♦ Safe, can bear long time work

ID		(Mpa) Working Pressure	(m) Length	(mm) Pipe Wall Thickness
mm	(mm) T	(Mpa) Working Pressure	(m) Length	(mm) Pipe Wall Thickness
250	±2	60mm mercury column Max vac 650mm high	1-3	31-32
300	±2		1-3	34-37
414	±2		1-3	35-37
560	±3		2-3	40-45
600	±3		2-3	40-45
700	±3		2-3	40-45
800	±4		2-3	50-52
900	±4		2-3	55-58
