MX1 MILLING MACHINE
Negotiable
/ Piece
1 Piece(Min. Order)
- T/T Credit Card
You May Like
-
MT8145 - BENCHTOP DIGITAL MULTIMETER
-
MCP MS506 analog multimeter 30V 10A
-
MCP SVM-001 STUDENT ANALOG VOLTAGE METER AC DC 1000V/ac dc voltmeter
-
MCP SAM-001 STUDENT ANALOG CURRENT METER AC DC/dc ac current meter
-
WD2250B - digital wattmeter
-
MCP WD2250A - watt meter/digital wattmeter/three phase watt meter
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | MCP | Model Number | MX1 | |
| CNC or Not | Normal | Voltage | 120/V230V | |
| Power(W) | 150 | Dimension(L*W*H) | 340mm X 320mm X 600mm | |
| Weight | 32kg |
Product Description
Specifications
.Variable speed.Over load protection
.Inside leadscrew
MX1 MILLING MACHINE
Features
.Variable speed
.Over load protection
.Inside leadscrew
| Technical Data | |||||
| Drilling capacity | 10mm | ||||
| End milling capacity | 10mm | ||||
| Face milling capacity | 16mm | ||||
| Table | Table size | 240×145mm | |||
| T slot (amount×width×distance) | 3×8mm×45mm | ||||
| Max. load | 20kg | ||||
| Travel | X travel | 180mm | |||
| y travel | 90mm | ||||
| Z travel | 230mm | ||||
| Spindle nose to table | 45~275mm | ||||
| Max. distance spindle to table | 220mm | ||||
| Spindle | Spindle taper | Mt2 | |||
| Spindle motor | 150W | ||||
| Spindle speed | 100~1000r/min.(low range) 100~2000r/min.(high range) | ||||
| Accessory | Φ10mm drill chuck, wrench set, oil can | ||||
| Power source | 230V or 120V | ||||
| Dimensions(W×H×D) | 340mm × 320mm × 600mm | ||||
| Packing size(W×H×D) | 410mm × 420mm × 660mm | ||||
| Weight | 32kg(NW)/44kg(GW) | ||||
