JIS DIN Marine Cast Iron Air Vent Head 53ON DN40-DN300
US$ 10 - 200
/ Piece
1 Piece(Min. Order)
- Qingdao China
- T/T
You May Like
-
Marine Air Vent Head JIS/DIN Aluminum DN40-DN300
-
Marine Air Vent Head JIS/DIN Galvanized Welding Steel DN40-DN300
-
JIS Marine Cast Iron Air Vent Head 53ON DN40-DN300
-
KS91A DN40-DN450 mm JIS DIN Marine Cast Iron Air Vent Head
-
JIS DIN Marine Air Vent Head Aluminum DN40-DN300
-
Marine Air Vent Head JIS/DIN Galvanized Welding Steel DN40-DN300
Product Details
| Standard or Nonstandard | Standard | Pressure | Other, Medium Pressure, 5K/10K | |
| Power | Other, Manual, Manual | Media | Other, Other, Air | |
| Port Size | JIS DIN, DN40-DN300 | Place of Origin | Shandong, China | |
| Model Number | JIS DIN AIR VENT HEAD | Application | General | |
| Structure | Other, Air Pipe Head | Material | Other, cast iron |
Product Description
Marine Cast Iron Air Vent Head 53ON DN40-DN300
MATERIALS OF MAJOR PARTS
| No | Description | Material |
| 1 | Hex.bolt/washer | STS 304 |
| 2 | Top Cover | SS 400 |
| 3 | Packing | Neoprene |
| 4 | Main Frame | FC 200 |
| 5 | Seat Packing | Neoprene |
| 6 | Hex.Bolt | STS 304 |
| 7 | Wire Net | STS 304 |
| 8 | Net Frame | SS 400 |
| 9 | Screen Cover | SS 400 |
| 10 | Disc | STS 304 |
| 11 | Packing | Neoprene |
| 12 | Spring Washer | STS 304 |
| 13 | Guide Bar | Stainless |
MAIN DATA FOR JOINING(mm)
| DIAM | FLANGE DIAM | PITCH | HOLE | KG |
| 50A | 130 | 105 | 4×15 | 11 |
| 65A | 155 | 130 | 4×15 | 12 |
| 80A | 180 | 145 | 4×19 | 17 |
| 100A | 200 | 165 | 8×19 | 24 |
| 125A | 235 | 200 | 8×19 | 31 |
| 150A | 265 | 230 | 8×19 | 48 |
| 200A | 320 | 280 | 8×23 | 67 |
INSTRUCTION
Produced accoridng to JISF7400 Standards. The flange standard can be chosen by customers.
ACCESSORIES
PACKAGING
