Home > Products > Displacer Level transmitter > LC3244LD FOXBORO ECKARDT Buoyancy Level Transmitter for Capacitive Liquid Level Sensor Alternatives Products
LC3244LD FOXBORO ECKARDT Buoyancy Level Transmitter for Capacitive Liquid Level Sensor Alternatives Products
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
LC3020 Gauge Measure Tool Intelligent Big Ball Float Liquid Level Transmitter
-
LC3010 FIELDVUE DLC3000 Series Intelligent Digital Height Gauge With Transmitter and HART Protocol
-
LC3244LD FOXBORO ECKARDT Best Selling Products Intelligent Electronic Level Transmitter for Liquid Control Meter Top Mounted
-
LC3244LD FOXBORO ECKARDT Buoyancy Liquid Level Transmitter With Intrinsically Safe for Electronic Levelling Instrument
-
AT100C Magnetostrictive Precision Level Digital Height Gauge for Electronic Level Transmitter
-
UHZ 517C70A Twin Chamber Double System for Depth Water Measure Fuel Level Gauge With Transmitter and HART
Product Details
| Place of Origin | Shanghai, China | Brand Name | FOXBORO/ECKARDT&XINGSHEN | |
| Model Number | LC3244LD |
Product Description
Specifications
1. suitable for small range, low density process conditions2. high accuracy
3. the sensor and key parts : FOXBORO ECKARD.
Measure range: liquid level: 0~5m density: 0~0.3 to 0~2.0g/cm3
Interface: density difference: 0~0.05 to 0~1.5g/ cm3
Accuracy: A class: ±0.2%FS; B Class: ±0.5%FS
Output: Analog--two wire 4~20mA DC;
Digital-- HART or FOXCOM Protocol;
FF Protocol.
Process temp.: -196~500°C Ambient temp.: -40~85°C (with LCD: -40~70 °C )
Safety class: Intrinsically safe: ExiaIICT1-4; Explosion-proof:ExdIIT1-T5
Enclosure: IP65 (NAME 4X)
Connection flange:
Material: carbon steel, 304SS, 316SS, 316L or on request
