LC3010 FIELDVUE DLC3000 Electronic Digital Level for Intelligent Displacer Liquid (interface) Level Transmitter
- Shanghai
- T/T Credit Card
You May Like
-
LC3010 FISHER FIELDVUE DLC3000 High Precision Digital Level for Displacer Level Transmitter
-
URS100M Static Pressure Level Transmitter
-
LC3144LD Foxboro Intelligent Buoyancy Level Transmitter for Foxboro Sensor Remote Transformer
-
LC3144LD Foxboro Cooperation Product for Water Level Sensor Side Mount With Cage
-
LC3244LD FOXBORO ECKARDT Intelligent Displacer Liquid (interface) Water Level Sensor for Measurement Tool Side Mount With Cage
-
LC3244LD FOXBORO ECKARDT Intelligent Buoyancy Liquid (interface) Water Level Transmitter for Measuring Tool Top Mount
Product Details
| Place of Origin | Shanghai, China | Brand Name | FISHER and FOXC | |
| Model Number | LC3010 |
Product Description
Specifications
1. FIELDVUE DLC3000 brand level controller2. stable performance
3. endurable
4. 420 centigrade 2500lb class 2500
Technique Parameter
Measure range: 0~3000m
Accuracy: ±0.5%FS; ±0.1%FS
Linearity: ±0.5%FS
Hysteresis: <0.2%FS
Repeatability: ±0.1%FS
Dead area: <0.2%FS
Power supply: 12V~30VDC; with reverse power protection in controller;
Output: Analog 4~20mA (direct); 20~4mA
Digital: HART1200 FSK
LCD: display analog value or level, temperature, torque tube rotation angle and % range.
Min density difference: 0.05g/cm3
Enclosure: NEMA4X and IEC60529 IP66
Model Table
LC3010 | Intelligent Displacer Liquid Level (Interface )Transmitter | Model Number | |||||||||
| 1 | HART | Communication | ||||||||
2 | F. FIELDBUS | ||||||||||
3 | FOMCOM | ||||||||||
| 1 | Q235 STEEL | Body Material | ||||||||
2 | 321 SCS321 1Cr18Ni9Ti 1.4873 | ||||||||||
3 | 316Ti OCr18Ni12Mo2Ti 1.4571 | ||||||||||
4 | 316 SVS316 OOCr17Ni12Mo2 1.4401 | ||||||||||
5 | 316L SVS316L OOCr14Ni12Mo2 1.4435 | ||||||||||
6 | other material to be specified. | ||||||||||
| H | External displacer side-side mounted | Mounting | ||||||||
C | External displacer side-bottom mounted | ||||||||||
F | External displacer top-side mounted | ||||||||||
G | External displacer top-bottom mounted | ||||||||||
N | Internal displacer top mounted | ||||||||||
| 1 | For liquid level | Service | ||||||||
2 | For interface | ||||||||||
3 | For density | ||||||||||
| 4/4A | 2.5MPa/Class 150LB ANSI | Pressure | ||||||||
5/5A | 4.0MPa/Class 300LB ANSI | ||||||||||
6/6A | 6.3MPa/Class 600LB ANSI | ||||||||||
7/7A | 16.0MPa/Class 900LB ANSI | ||||||||||
8/8A | 32.0MPa/Class 1500LB ANSI | ||||||||||
9/9A | 40.0MPa/Class 2500LB ANSI | ||||||||||
| T1 | Normal temp.:-40°C~150°C | Process | ||||||||
T2 | High temp.-150°C~400°C | ||||||||||
T3 | Low temp.-196°C~150°C | ||||||||||
| O | No explosion-proof . | Safety Class | ||||||||
D | Explosion-proof: ExdIICT1~T6 | ||||||||||
E | Intrinsically safe: ExiaIICT1~T6 | ||||||||||
B | with safety barrier (See Operation Manual) | ||||||||||
| 0 | without heating jacket | Accessories | ||||||||
J1 | heating jacket / process conn. | ||||||||||
J2 | heating jacket / process conn. | ||||||||||
|
| Measure Range | |||||||||
|
| Medium Density | |||||||||
