Product Details
| Condition | New | Type | Freeze Drying Equipment | |
| Place of Origin | Shanghai, China | Brand Name | LYOMAC | |
| Model Number | lyopro-1.0,2.0,3.0,5.0,7.5 | Voltage | 380/440V, 50/60Hz | |
| Power(W) | 16~51KW | Dimension(L*W*H) | 5000*1200*2500 | |
| Weight | 3000KG ~ 8000KG | Certification | CE TUV / GB150 /FDA 21 CFR/cGMP | |
| Warranty | 16 months after delivery | After-sales Service Provided | Overseas service center available |
Product Description
This freeze dryer has reliably running in last decade! it has installed in USA, Russia ,India and latin America countries. and with CIP&SIP. SCADA system available. perfect for pilot scale production for vial and clinical materials. we offer all standard with FDA &cGMP regulation.
- Compact design,
- Reliability running under high performance,
- vacuum or air filled stoppering,
- Eutectic device detector are available.
- Control system designed with multi-recipe, user can choose different recipe for different process.
- The control system can automatically validate the machine performance before each production cycle, thus the safety for each production cycle can be ensured.
- Eutectic point detector
- Organic solvent collector.
- Inter-shelf distance adjust mechanism
- Vacuum or air filled stoppering (with pressure adjustable)
- Auto moisture judgment on control system
- CIP/SIP
- Chamber isolation valve with mushroom/butterfly type.
- Constant height loading
- Chamber door with auto/manual lock
- Chamber vacuum adjust function
- Qualification document: IQ,OQ,DQ
Type | LYOPRO-1.0 | LYOPRO-2.0 | LYOPRO-3.0 | LYOPRO-5.0 | LYOPRO-7.5 |
Shelf area (m2) | 1.08 | 2.16 | 3.24 | 5.40 | 7.56 |
Shelf size (L*W*T)(mm) | 600*450*20 | 900*600*20 | 900*600*20 | 1200*900*20 | 1200*900*20 |
Useable Shelf No. | 4 | 4 | 6 | 5 | 7 |
Vial loading quantity Φ16 Φ22 | 4400 2200 | 9000 4500 | 14000 7500 | 20000 10000 | 32000 16000 |
Inter. Shelf distance(mm) | 100 | 100 | 100 | 100 | 100 |
Ice capacity (KG) | 20 | 40 | 60 | 100 | 150 |
Shelf ultimate cooling temperature(°C) | ≤50 Min | ≤50 Min | ≤50 Min | ≤50 Min | ≤50 Min |
Condenser ultimate cooling temperature(°C) | -75 | -75 | -75 | -75 | -75 |
Ultimate vacuum(Pa) | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 |
Installation dimension(L*W*H)(mm) | 3000*1200*2600 | 3800*2000*2600 | 4000*2000*3000 | 5000*1750*3100 | 6000*1750*3600 |
Weight(Kg) | 2000 | 3500 | 4500 | 7500 | 8500 |
Power(KW) | 16.5 | 22.0 | 28.0 | 41.0 | 51.5 |
LYOMAC TECHNOLOGY CO., LTD. is a professional manufacturer of Vacuum freeze dryer (Lyophilizer) for pharmaceutical, nutraceutical, and food industries. We supply various range of freeze dryer, from drying capacity: 1 Liters to 2000Liters. Company located at Shanghai.
Lyomac has more references installation in different countries. And get FDA and CE compliance.
The basis of our success is not only supply reliable and quality dryer, we help our customer on refurbishing and training service for different brands of freeze dryers.
Lyomac has always required one thing from its freeze dryer. That they are the best. And because we know what's important to you, we develop our freeze dryer solution according to your exact needs.
This is what our business is based on. After all, some things haven't changed from the begin of our company established: your high demands for an economical, reliable and safe drying process of your valuable materials.
We secure our international clients added value with clever ideas, first-class service and high-end products.
Company has passed CE certification, ISO9001:2000 certification, to know more about us, please visit more on web or contact directly.
