BG2-80 2 Color Automatic Penholder Screen Printer With CE,ISO

Product name

Model No

Certificate

CE, ISO-9001-2000

Brand Name

Description

1. One operator, the two orbits can work at the same time. The machine can be stopped to clean screen frame, adding ink at any time, and the machine designed specially to make sure the pen-holder won’t be scorch and out of shape when the machine stop working.

The printing objects won’t be scorch and out of shape when the machine stop.

2. It can print conicity products, and the maximum conicity is 3°.

3.The printing baseplate has the vacuum function(optional) which can ensure the precision of registering.

5. The machine can printing two differents patterns or different kinds of pen-holders at the same time.

6. It have dust-abatement device (optional), which can clean dust on pen-holder before printing.

7. Double scrapers design to keep printing and ink flooding perfectly and reliable.

Advantage

1. Full electric control, no need compress air, and automatic register control.

2. Uploading and downloading pen-holder automatically, The machine can printing in 1 or 2 orbits, and printing patterns in 1 or 2 colors.

3.The machine run smoothly, and the printing speed and printing stroke are adjustable.

4.Taiwan made transducer which ensure the printing effect consistently.

5.Adopt IR infrared ray (or UV ultraviolet radiation drying system, optional), printing and drying can be finished at the same time.

6.Application: The machine be widely used in the printing of ball pen, water erasable pen, pencil, marker pen, eyebrow pencil, lipstick, medical test tube, etc.

Parameter

1.Diameter of printing objects:   1 color : φ3~φ20mm     2 color: φ8~φ20mm

2.Length of printing objects: 60~160mm

3.Width of printing route: 20~80mm

4.Printing speed:  1 color: 7200pcs/hr    2 color: 3600pcs/hour

5.Power: 220V  50/60Hz  6.3KW

6.Weight :630kg

7.Machine Dimension: 3200×1120×1520mm
