Silk Mesh Tighten Machine TM-1600LA Silk Screen Mesh Stretching Machine

Silk Mesh Tighten machine TM-1600LA

is characterized not only for its ingenious,practical and elegant appearance,but also for its firm structure, light weight, durability and reliability and has therefore become an un-substituting product in the silk-screen industry.

which are connected into a rectangle stretching area.With the chain-drive and trapezium whorl silk-pole-moving structure,the machine operator can easily control the tensile strength of the stretcher by turning the plastic covered handle.

The lamination of the frame and the stretching surface is finished by the moving of the four cylinder, The stroke of the cylinder can be used for varied thickn-ess of frames by adjusting the spiral bolt and therefore guarantee the quality of the silk net.

TM-1600LA  TM-2500LA Mesh tighten machine the frame is light and firm; the silk pole moving structure is accurate and has outstanding self-lock function;the chain driving structure is light and reasonably distributed; the net collets are composed with reliable and firm double rocker which is patented by YongAn's only.Strong clamping force is the main reason to decide the quality of net stretching and our product is right beyond all other products at this point.

1.Model number:TM-1600LA
2.Max. screen drawing area:1200*1600mm
3.Min. Screen drawing area:800*800mm
4.Max. tension:≥50N/CN
5.Machine shape  size (mm):1800×1400×760(L×W×H)
6.Weight:165kg

1.Model number:TM-2500LA
2.Max. screen drawing area:1500*2500mm
3.Min. Screen drawing area:1200*1200mm
4.Max. tension:≥50N/CN
5.Machine shape  size (mm):2700×1700×760(L×W×H)
6.Weight:195kg
