DVP-750 Digital Optical fiber fusion splicer(splicing machine)

FOB Price

Negotiable / Piece

50 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	LE DVP KL
Model Number	730 Auto & Manual Single Fiber Fusion Splicer

Core Cladding Alignment Single Fiber Fusion Splicer
Core alignment
auto calibrate parameter

Specification

1. high definition LCD display
2. PAS technology
3. core or cladding alignment

Description

1. high definition LCD display
2. PAS technology
3. core or cladding alignment

4. Double heaters, 30 sec. tube- heat time

5. 3magnification modes, max. 360 magnification

6. 4 display modes, fiber core visible

7. 8 Sec. splice time

8. Lithium battery

9. Max. wind velocity of 15m/s

10. splicing method: auto , manual

11. store 8000 groups of splicing results

12. USB interface

Parameter

Applicable fibers	SM, MM, NZ-DS(G655), EDF and others
Average splice loss	0.02dB(SM),0.01dB(MM). 0.04dB(NZDS)
Return loss	≥60dB
Tension test	2.0N(200gf)(Standard)
Protection sleeve length	20mm, 40mm, 60mm and other series micro protection sleeves
Splicing program	80 groups
Language	English, Chinese, Korean, Russian, Spanish , French, German,
Language	Portuguese and others
Environment conditions	-25~+50°C (operation temperature), 0~95%RH (humidity), 0~5000m (altitude)
Storage environment	-40~ +80°C (temperature) , 0~95%RH (humidity)
Power supply	AC adaptor: 85~260V input voltage
Power supply	Internal battery: 12V,8Ah, up to 180 times of continuous splice and heat
Dimensions/Weight	140(D)×150(W)×160(H)mm/2.8kg

Including

Main body

• Internal Battery

• Charger

• Spare Electrodes

• Cooling Tray

• Manual Instruction

• Carry Case

• Fiber Cleaver

• Fiber Stripper

• AC Adaptor

• AC Power Cord

Main Machine
