24PinCentronic Connector Solder Cup Contacts (Male) Easy Type Certified ULE
- Guangzhou
You May Like
-
Centronic IDC for Flat Cable Type Connector With Spring Latch Socket
-
Centronic IDC for Flat Cable MD Type Connector Male
-
TYCO Connector Solder Male PCB Centronic Certificated UL E346172
-
57 Series Solder Male PCB Centronic Connector Certificated UL E346172
-
57 Series Micoro-ribbon Centronic Solder Classic Type With 90 Degree Cable Exit Angle Male Connector
-
AMP SOLDER CENTRONIC CONNECTOR GOBI CLASSIC TYPE (MAL)
Product Details
| Place of Origin | Guangdong, China | Brand Name | FUYCOONN | |
| Model Number | FUY57064 | Type | Other, 57 Series Connector | |
| Application | Other, Power, Cable | Gender | Female |
Product Description
Specifications
1.14,24,36,50,64Way Telecom Systom Female Connector2.Solder Cup Contacts Type Connector
3.UL-94-VO,ROHS
4.ISO 9001:2008
Specifications
1) Product features
1. Product Type: Connector
2. Product Line:CENTRONIC
3. Connector Style: Female
4. Certerline :2.16mm(0.85 in)
5. Number of Position:14,24, 36,50,64 pin
6. Contact Material: Copper Alloy
7. Contact Plating: Gold (A:5u" ,B:10u",C:15u"A:30u'')
8. Comb Material:Thermoplastic
9. UL Flammability Rating: UL-94-V0
10. Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
11. Orientation:Standard
12. Special Function:(Pan Holes)
A: Screw Lock B:Rivet Insert
C: 4.8mm Hex Screw Lock
D: IEEE488 Hex Screw Lock
2) Electrical Specifications
1. Current Rating: 5Amp
2. Voltage rating: DC 1000v per minute
3. Insulator Resistance: 1000Mn MIN.(at 500V DC)
4. Operation Temperature: -55°C to +105°C
3) Order Information
Remark : 1. This is general information for each of order.
2. Plz reference to filling out this form before inquiry.
3. We will feedback the latest information to you on time.
4. We are look forwar to long term business cooperation with you.
