Centronic Connector PCB DIP Right AngleSocket Type
- Guangzhou
You May Like
-
57 Series Centronics PCB Mounting Right Angle DIP Solder Receptacle Connector Female Champ 2.16mm Pitch
-
2.16mm Pitch Champ Amphenol 957 100 Pin Reversed Connector Right Angle PCB MountingType DIP Termination Female Receptacle
-
Centronics Champ PCB Mounting Right Angle Connector Female Receptacle With Bail Clip
-
TYCO 50 Pin Centronic PCB DIP Right Angle Type Connector Female
-
PCB Mounting Right Angle Female 2.16mm Centerline Pitch Champ Connector DDK DIP Type With Bail Clip
-
Centronics Right Angle PCB Mounting Reversed Connectors Female Receptacle With Board Lock
Product Details
| Place of Origin | Guangdong, China | Brand Name | FUYCOONN | |
| Model Number | FUY57076 | Type | Other, 57 Series Connector | |
| Application | Other, Power, Cable | Gender | Other, Female, Female |
Product Description
Specifications
CENTRONIC PCB CONNECTORRack and Panel Assembly
90 DEG Cable Exit Angle
Solid Copper Conductor
Compliance:ROHS
Specifications
1) Product features
1. Product Type: Connector
2. Product Line:CENTRONIC
3. Connector Style: Female
4. Certerline :2.16mm(0.85 in)
5. Number of Position:14,24, 36,50,64 pin
6. Contact Material: Copper Alloy
7. Contact Plating: Gold (A:5u" ,B:10u",C:15u"A:30u'')
8. Comb Material:Thermoplastic
9. UL Flammability Rating: UL-94-V0
10. Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
11. Orientation:Standard
12. Special Function:(Pan Holes)
A: Screw Lock B:Rivet Insert
C: 4.8mm Hex Screw Lock
D: IEEE488 Hex Screw Lock
2) Electrical Specifications
1. Current Rating: 5Amp
2. Voltage rating: DC 1000v per minute
3. Insulator Resistance: 1000Mn MIN.(at 500V DC)
4. Operation Temperature: -55°C to +105°C
3) Order Information
Remark : 1. This is general information for each of order.
2. Plz reference to filling out this form before inquiry.
3. We will feedback the latest information to you on time.
4. We are look forwar to long term business cooperation with you.
