2.16mm Pitch Champ DDK Male Plug 25 Pairs 50 Pin Solder Cup Connector With Right Angle Cable Exit
US$ 1.5 - 3
/ Piece
1000 Pieces(Min. Order)
- Shenzhen / Guangzhou
- T/T Credit Card
You May Like
-
DDK Champ Male Plug 50 Solder Cup Pin Hard Connection Header Connector Wih Side Cable Exit Plastic Cover
-
Ribbon 50 Pin Champ 25 Pair Solder Cup Ribbon Male Plug Pin Header Hex Head Nuts Connector Certificated UL
-
50 Way Male Plug Connector Solder Cup Contact 2.16mm 25 Pair Header Hex Head Nuts
-
50P Hard Connection Solder Cup Contacts Connector Plug Male 25 Pair Solder Ribbon Cable Header With MD Shape Shell
-
50 Way Solder Cup Contact PBT Connection Connector Male Plug Type 25 Pair DDK Ribbon Header
-
50 Way Centronic Solder Cup Pin Connector Male Plug DDK Header Connector for Ribbon
Product Description
Specifications
Item No.: FUY571061,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample
Specifications
Product features:
Product Type: Connector
Product Line:CENTRONIC/CHAMP
Connector Model:FUY57107
Connector Style: Male
Orientation: Reverse Orientation
Mechanical Attachment:
Plate Mertial: Nickel Plated Stell
Profile: Tapered Type
Connector Core Material:Thermoplastic
Terminal Related Features:
Certerline :2.16mm(0.85 in)
Number of Position: 50 pin
Contact Plating: Gold (A:5u" ,B:10u"C:15u",D:30u")
Contact Material: Copper Alloy
Housing Features:
Connector Style: Plug
Housing Material: All Plastic Cover
UL Flammability Rating: UL-94-V0
Finish
Electrical Specifications:
Current Rating: 5Amp
Voltage rating: DC 1000v per minute
Insulator Resistance: 1000Mn MIN.(at 500V DC)
Operation Temperature: -55°C to +105°C
Technical Parameters
Application
All designed for use in industrial,commercial;
telecommunication systems;VDSL Teleccom Equipment ;
Computer Peripherals;healthcare, aerospace ;
Communication networks,automotive;data communications;
consumer devices; defense marine.
