MDCE-5C Digital Microscope Camera Trinocular Microscope With Camera

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	YanHe		Model Number	MDCE-5C
Place of Origin	Shanghai, China

Description

·	Adopt high performance USB2.0 chip.
·	With high-resolution 1280X1024 (1.3M Pixel), avoid mosaic phenomenon and make image fluent. Provide auto brightness and white balance control function and some high-level image control function such as color saturation, contrast, fringe swell and gamma numerical value.
·	With 30f/s high image transmission speed, makes image transmission more fluent and realistic.
·	Convenient to use and just insert it into eyepiece tube or top tube of trinocular head. Easy to install and operate and it can be plug and unplug freely.
·	USB2.0, plug-and-play, easy to install and use.
·	With measurement functions, it is an outstanding assistant in medicine, teaching, industrial test field and other sectors.

Specification

	MDCE-5C
Image Sensor	1/3.2"CMOS
Image Format	640×480,800×600,1024×760,1280×1024
Data Format	YUY2,1420
Image Output	USB2.0, plug-and-play
Connecting Mode	Insert it into Eyepiece Tube of Microscope Directly (23.2mm or 30mm)
Image Velocity	30PfS@VGA(I420) 15PfS@VGA(YUY2)
Lowest Illumination	2.5LUX
SNR	>48dB
Camera Image Control	Saturation, Contrast, Sharpness and so on
White Balance	Auto, Manual
Exposure	Auto, Manual
Working Current	<200mA
Dormant Current	<1mA
Storage Temperature	-20℃~+60℃
Working Temperature	0℃~+40℃

	MDCE-5C
Digital Camera Eyepiece	A
Driver	A
Eyepiece Tube Adapter	A
Packing Box	A
Note:"A" Standard Outfit,"O" Optional
