Air To Water Heat Pump Low Temperature Split EVI Heat Pump Water Heater

Specifications

multi-function air to water heat pump

Wide application

Widely used in hotels,restaurants,apartment houses, villas, factories and schools, sauna, bathroom, SPA association, beauty salon, fitness center, swimming pool, aquaculture, etc to applicate with various terminal equipment (fan coil, floor heating, radiators, temperature-holder tank etc.), combining indoor luxury decoration, maximizing satisfy user's requirements and comfortable. The modular structure is suitable for various sizes of engineering, office buildings, hotels, restaurants, cinema, shopping plaza, gymnasium, hospital etc., as the best choice of various public places.

High efficiency and energy saving

Using energy efficient scroll compressors heat exchanger (316 stainless steel material welded plate heat exchanger, high efficient S&C heat exchanger and rotory tube heat exchanger) small volume, heat exchang ability, so the same old products to improve energy efficiency is 10%.Comprehensive energy consumption is only65% of  the solar energy water heater,25% of electric water heater. When it is cooling+heating,the COP will be more than 6.

Flexible configuration

The unit and tank flexible configuration.A different water tank to choose,pressure or open type connected to meet the different demands of clients.

Flexible installation position

Host appearance, compact tank to small occupation space for installation, conduit length of flexible connection.

Hot water circulation heat straight

55 degrees hot water heated one-time and got directly to use, improve comfort of water using and stable of unit. When stop to use water in a long time and the water temperature drops, unit will heat cyclely and automaticly.

Dual-core design

Heat pump, electric auxiliary heat integration together, super energy-saving and hot water in all-weather.

The advanced control technology of water

WEILO water pump built-in,with water flow protection, automatic filling and water level control, automatic water pressure test, hydrating pressurization control and Automatic constant temperature adjustment.

Integrated design,multi-protec and reliable

Integration design, system sealed welding completely, just conduit connections, without refrigerant pipe connections, simple and reliable connection installed. built-in protections of hot water flow and air flow, compressor exhaust temperature, high and low pressure compressor, compressors flow and power fault phase, power supply fault and  lack of phase ,freeze protection, automatic defrost and automatic load adjusting etc built-in.Multiple protections.

Environment Friendly

Using refrigerant 407C or 410A, no damage,environment friendly.

Dual-core design

Heat pump, electric auxiliary heat integrated together (optional), super energy, which can meet all-weather hot water supply.

Simple operation

Intelligent design, LCD display, simple operation, free setting during 30 ° c - 60° c . and cycle timing set on/off freely.Power failure memory function.

Quiet running

Using efficient, low-noise rotary, closed scroll compressors and low-noise fan,ensure quiet running.

Working environment

Applicable to -15~45- the outdoor harsh environment temperature, all-weather work.
