CE RoHS Certification S-2000-27V Input 200~260v Output 27v 2000w Power Inverter

SPECIFICATIONS

OUTPUT

Model

S-2000-12

S-2000-24

S-2000-27

S-2000-48

DC Voltage

12V

24V

27V

48V

Rated Current

166A

80A

70A

40A

Current Range

0-166A

0-80A

0-70A

0-40A

Rated Power

1992W

1920W

1890W

1920W

Ripple & Noise

240mVp-p

240mVp-p

240mVp-p

300mVp-p

Voltage Adj. Range

10.8~13.2V

 20~26.4V

 24~30V

 41~56V

Voltage Tolerance

±5%

±5%

±5%

±5%

Inlet Stability

±1%

±1%

±1%

±0.5%

Load Stability

±1%

±1%

±1%

±0.5%

Setup, Rise, Hold Up Time

800ms, 50ms, 16ms at full load

INPUT

Voltage Range

220VAC±20%   47~63 Hz(110VAC can be customised )

AC Current

15A/230VAC

Efficiency

75%

75%

76%

80%

Inrush Current

30A/115V  60A/230V

Leakage Current

<3.5mA/240VAC

PROTECTION

Over Load

105%~135% Type:plusing hiccup shutdown Reset:auto recovery

Over Temp.

RTH>=80 output shutdown

ENVIRONMENT

Working Temp., Humidity

-10 degrees~+60 degrees (Refer to output derating curve),20%~90%RH

Storage Temp., Humidity

-20 degrees ~+85 degrees, 10%~95%RH

Temp. Coefficient

±0.03%/ degrees (0~50 degrees)

Vibration

10~500Hz,2G 10min,/1cycle,Period for 60min,Each X.Y.X axes

SAFETY

Withstand Voltage

I/P-O/P: 1.5KVAC   I/P-FG: 1.5KVAC   O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD

Safety Standard

Meet UL1950requirement(Not apply for the mark)

EMC Standard

CISPR22(EN55022),IEC1000-4,2,3,4,5,6,8,11 IEC1000-3-2

OTHERS

Dimension

410*220*150mm (L*W*H)

Weight

11Kg
