single core armoured cable , single core shielding cable

Type

Description

Application n

Cu

Al

YJV

YJLV

XLPE insulation PVC sheath power cable

To be laid indoors, in tunnel, cable furrow or pipe, the cable couldn't bear mechanical force outside

YJY

YJLY

XLPE insulation PE sheath power cable

YJV22

YJLV22

 XLPE insulation, steel tape armor,  PVC sheath power cable

To be laid underground, the cable could bear certain mechanical force, but it couldn't bear great pulling force.

YJV23

YJLV23

XLPE insulation, steel tape armor,  PE sheath power cable

YJV62

YJLV62

XLPE insulation, have no the magnetism steel tape armor,  PE sheath power cable

YJV32

YJLV32

XLPE insulation, thin steel-wire  armor,  PVC sheath power cable

Be applicable to the well, water inside and fall in the bad soil, the cable cans bear the equal dint outside the machine with pull the dint

.

YJV72

YJLV72

XLPE insulation, have no the magnetism thick steel-wire  armor,  PVC sheath power cable

YJV42

YJLV42

XLPE insulation, thick steel-wire  armor,  PVC sheath power cable

Be applicable to the well, underwater with the bottom of sea, the cable cans bear the bigger pressure with lead to pull the dint.

Special

Note

,6272.,.

The single-core magnetism material packs the cable is not suitable for to use for the AC power supply back track, the necessity hour eligibility uses the single-core 62 or 72 type pack the cable.

Disallow the cent to cross the magnetism piping mutually when single-core cable establish, the in order to prevent results in the descent that cable transport electric current ability.

Type

Description

Application

VV

VLV

PVC insulated PVC sheathed power cable

To be laid at indoor, tunnel and tube .

Cable cannot under take mechanism outside force

VY

VLY

PVC insulated and PE sheathed power cable

Can be laid at indoor,

tunnel tube and serious polluted places.

Cable cannot  undertake mechanism outside force

VV22

VLV22

PVC insulated steel belt armored

and PVC sheathed power cable

Can be laid at indoor, tunnel tube and mining well.

Cable cannot undertake mechanism outside force

VV23

VLV23

PVC insulated steel belt armored

and PE sheathed power cable

Can be laid at indoor,

tunnel tube mining well and serious polluted places.

Cable cannot  undertake mechanism outside force

VV32

VLV32

PVC insulated fine steel wire armored

PVC sheathed power cable

Can be laid at indoor, underground and mining well .

Cable can  undertake mechanism outside force

VV33

VLV33

PVC insulated fine steel wire armored

 PE sheathed power cable

Can be laid at indoor, underground .

Cable can under take mechanism outside force

VV42

VLV42

PVC insulated thick steel wire armored

 PE sheathed power cable

Can be laid at indoor, underground,mining well .

Cable can under take mechanism outside force

VV43

VLV43

PVC insulated fine steel wire armored

PVC sheathed power cable

Can be laid at indoor, underground ,

mining well and the places
