AC Power Supply 500W Inverters DC Power Supply (MSI-500)
- ZhaoQing
- T/T
You May Like
-
DC AC Power Supply Inverters 300W Household Power Inverters (MSI-300P)
-
China Factory 400W DC to AC Inverter / Solar Inverter (MSI-400)
-
150W DC to AC Inverter With USB Micro Inverter (MSI-150)
-
CE RoHS 100 Watt DC to AC Mini Car Inverter (MSI-100)
-
High Quality 200W Mini Portable Power Pack Inverter (MSI-200)
-
300W 12V Power Inverter Frequency Inverter DC to AC (MSI-300)
Product Details
| Place of Origin | Guangdong, China | Brand Name | Marshell | |
| Model Number | MSI-500 | Output Power | Other, 1000w | |
| Output Type | Single | Size | 193*124*54mm | |
| Weight | 0.83Kg | Input Voltage | 12V/24V | |
| Output Voltage | 100~120V/220~240V | Type | DC/AC Inverters | |
| Output Frequency | 50Hz / 60Hz±3Hz | Output Current | modified sine wave |
Product Description
AC Power Supply 500W Inverters DC Power Supply (MSI-500)
Marshell power inverter protect function:
1. Overload protection: Automatically shuts down when continuousdraw exceeds rated continuous watt;
2. Over voltage protection: Automatically shut down when input exceeds 16±1VDC;
3. Low voltage Alarm: Audible when battery dischargesto 10.5±0.5VDC;
4. Under voltage protection: Automatically shuts down when input is less than 10.0±0.5VDC;
5. Output voltage range 115V±10% AC (RMS)230V±10% AC (RMS);
6. Output frequency 60±3Hz 50±3Hz;
7. Thermal protection: Automatically shuts down when housing temperature exceeds 70 centigrade.
AC Power Supply 500W Inverters DC Power Supply (MSI-500) Specifications
Model | MSI-400 | MSI-500 | MSI-600 | MSI-800 |
Continuous Output Power (Watt) | 400 | 500 | 600 | 800 |
Output Peak Power (Watt) | 800 | 1000 | 1200 | 1600 |
Input Voltage (DC) | 12V(11~15V) / 24V(21~29 ) V / 48V(42~58V) | |||
Output Voltage (AC) | 100~120V / 220~240V | |||
Frequency | 50Hz / 60Hz 3Hz | |||
Output Waveform | Modified sine wave | |||
Efficiency | 85~90% | |||
Low Battrey-voltage Alarm (Volt) | 10V±0.5V/21±1V/42±2V | |||
Low Battrey-voltage Shutdown (Volt) | 10V±0.5V/20±1V/40±2V | |||
Over temperature shutdown | < 65°C | |||
Available Protection | overload protection, input reverse protection, short circuit protection | |||
Cooling Mode | By Fan | |||
Replaceable Fuse | 25A*2 | 30A*2 | 35A*2 | 30A*3 |
Accessory | Alligator clips(included) | |||
Dimension(L*W*H)mm | 193*124*54 | 193*124*54 | 185*125*70 | 220*125*70 |
Weight(KGS) | 0.82 | 0.83 | 1.55 | 1.85 |
QTY(PCS) | 20 | 20 | 10 | 10 |
Carton Measurement(CM) | 47.6*28*42.3 | 47.6*28*42.3 | 42*28.5*44.8 | 42*28.5*44.8 |
Container 20FT(PCS) | 8800 | 8800 | 5850 | 5850 |
AC Power Supply 500W Inverters DC Power Supply (MSI-500)
