Home > Products > other group > Walkie Reach Truck 2.5t Electric Reach Forklift Truck (CBD25)
Walkie Reach Truck 2.5t Electric Reach Forklift Truck (CBD25)
Negotiable
/ Unit
1 Unit(Min. Order)
- shanghai
- T/T
You May Like
-
Truck 2.5t Electric Reach Forklift Truck for Sale (CBD25)
-
Battery Reach Forklift Truck With 2.5 Ton Lifting Capacity (CBD25)
-
Reach Forklift 1.6t Mini Electric Reach Forklift (CQD16)
-
Manufacturers Reach Truck 1.6t Electric Reach Truck (CQD16)
-
Load Capacity 1600kg Battery Reach Forklift (CQD16)
-
Marshell 1.6t Small Electric Reach Stacker (CQD16)
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | Marshell | Model Number | CBD25 | |
| Type | Powered Pallet Truck | Power Souce | AC Motor | |
| Rated Loading Capacity | 2500 | Max. Lifting Height | 205mm | |
| Min. Lifting Height | 85mm | Fork Length | 1492mm | |
| Fork Width | 550mm | Overall Dimensions | 2300x790x1450mm | |
| Certification | CE | After-sales Service Provided | Overseas third-party support available |
Product Description
Walkie Reach Truck 2.5t Electric Reach Forklift Truck (CBD25)
Main configuration
1 maintenance-free AC drive system
2, the electronic steering system
3,24V / 270Ah capacity of lead-acid batteries
4, Curtis AC controller
5, imported hydraulic power unit
6, can quickly replace the battery side pull structure
suitable mode
1, relatively flat cement or similar hard surface
2, suitable for single pallet cargo handling
3, for high frequency, heavy load cargo handling
4, the working time of about 6 hours
TIPS
Does not apply to contain flammable and explosive gas or dust
Walkie Reach Truck 2.5t Electric Reach Forklift Truck (CBD25)
| Item | Parameters | unit | |
| Rated Loading | 2500 | kg | |
| Loading center distance | 600 | mm | |
| Overall Length | 2302 | mm | |
| Overall Width | 790 | mm | |
| Height(handle) | 1497 | mm | |
| The minimum height of fork | 85 | mm | |
| Fork maximum lifting distance | 205 | mm | |
| Ground Clearance | 25 | mm | |
| front wheel tread | 365 | mm | |
| Wheelbase | 1492 | mm | |
| Fork outside spacing | 550 | mm | |
| Fork inside spacing | 180 | mm | |
| Maximum lifting speed | without loading | 25 | mm/s |
| full loading | 20 | mm/s | |
| Maximum running speed | without loading | 6 | km/h |
| full loading | 6 | km/h | |
| Minimum outside turning radius | 1475 | mm | |
| Full-load maximum gradeability | 5 | % | |
| No-load maximum gradability | 8 | % | |
| Weight(without loading) | 680 | kg | |
| Battery | 24/270 | V/Ah | |
Walkie Reach Truck 2.5t Electric Reach Forklift Truck (CBD25)
