aluminum concrete formwork

Aluminum Formwork System

System Introduction:

Luowen Aluminum Formwork System is a kind of integrate construction formwork system. mainly made up of aluminum frame and formwork system, adjustable steel props, outer corner, inner corner, backing, pins, etc..

Characters:

1,Easy

It is about 23-25kg/m², light weight means only a single worker could move the Aluminum Formwork easily.

2,Efficient

The Aluminum Formwork System is jointed by the pin, it is two times fast than wood formwork to install and dismantle, so it could save more work and work time.

3,Saving

The Aluminum Formwork System supports early-dismantling application, the construction working cycle is 4-5 days per floor, it is effective for cost saving in human resource and construction management

The Aluminum Formwork can be re-used more than 300 times, the economic cost is very low of every time using.

4,Safety

The Aluminum Formwork system adopts the integrative design, it could load 30-40KN/ m², which could reduce the safety loophole leaded by the construction and materials.

5,High quality of construction

The aluminum formwork is made by extrusion process, it makes the concrete surface flat,smooth. No need heavy backing plaster, effectively for plaster cost saving.

6,Environment friendly

The aluminum material of the formwork could also be recovered after useless, it avoids the waste.

7,Clean

Different with the wood formwork, there is no wood panel,fragment and other waste in the construction area using the aluminum formwork.

8,Widely scope of application

The Aluminum Formwork System is suited for application of walls, beams, floors, windows, columns, etc.

...
