18MM particle board plant producing line
- qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Boring Machine | |
| Place of Origin | Shandong, China | Brand Name | shining asia | |
| Model Number | 30000M3 | Voltage | 380V | |
| Power(W) | 10000kw | Certification | ISO9004 | |
| Warranty | 3years | After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
partcle baord prodution line30,000CUBIC METER/YEAR 100 m3/day, 22.5hours/day, 300days/year,SURFACE SIZE: 1220x2440MM,THICKNESSPARTICLE BOARD PRODUCTION LINE
MACHINES AND EQUPMENT LIST
PRODUCTIONE LINE SPECIFICATION:
30,000CUBIC METER/YEAR(100 m3/day, 22.5hours/day, 300days/year)
SURFACE SIZE: 1220x2440MM,THICKNESS: 6~25MM
Chipper Section
NAME | Description |
drum chipper | BX218 |
belt conveyer | 10000×500mm |
magnet |
|
chip silo | 50 m3 |
Flake Section
NAME | Description |
belt conveyer | 500×6000mm |
pulverizer | 37KWX2 |
flake pipeline | 7000mmX2 |
flake silo | 480m3 |
hopper | 10000×8000×2000mm |
screw feeding out pipe | 4000mm |
belt conveyer | 6000mm |
magnet | |
screen | 6000 mm×1500mm |
belt conveyer of unqualified flake | 6000mm |
Screw conveyor | 4000mm |
dryer | 12000mm×1600mm |
sieve | 1500mm×6000mm |
hopper |
|
Screw conveyor & belt conveyer | 3000mm+8000mm |
core flake silo | 30m3 |
Surface flake silo | 50m3 |
Screw conveyor | 4000mm |
Glue Section
NAME | Description |
glue vat | 6000mm×2000mm |
glue pump | 0.7 KW X2 |
glue blender | 2000×500mm, 18KWX2 |
belt conveyer | 1000mmX2 |
Forming & Pressing Section
NAME | Description |
forming machine | 1800mm×6000mm |
belt conveyer | 1500×2800mm |
belt conveyer with centering device |
|
pre-press | 2400mm |
belt conveyer | 1500×1500mm |
edge trim saw for mat-board | 2.2 KW-2 X2 |
cut saw | 2.2 KW-2 |
belt conveyer | 1500×3000mm |
Accelerate belt-conveyer | 1500×4000mm |
belt conveyer | 1500×3000mm |
scale | 1500×3000mm |
unqualified board collect system | 500×6000mm |
belt conveyer | 1500×3000mm |
Accelerate belt-conveyer | 1500×4000mm |
board carrier and baffler | 3KW |
|
|
loader | 4200mm |
hot press | Hot platen size: 2700×1560×90mm Hot platen number:13pcs, Cylinders diameter & number:Φ320×6 |
Same time closing device |
|
unloader | 4000mm |
roller conveyer | 1000×2200mm |
turner cooler | 2900mm |
turner conveyer |
|
edge trim saw for finished board | 5.5KW×4 |
roller platform conveyer |
|
lifter | 3KW |
Oil Boiler
NAME | Description |
oil boiler | 1600000kcal/h |
Sanding Section(optional)
NAME | Description |
board pusher | Φ50×500mm X2 |
lifter | 3KW,1250×2500mm X2 |
roller conveyer | 1500×3000mm |
sander | 3-head |
roller conveyer | 1500×3000mm |
lifter | 2800×1500mm X2 |
air compressor | 5.5KW |
de-dust pipeline |
|
de-dust blower | 22KW |
de-dust silo | 10000×8000×5000mm
|
Japanese PLC electric system |
|
workshop: area2000M2, length100m,width20m
Machine Pictures:
please contact me frequently if you have interesting about it.
linyi shinning asia industry CO.,LTD
tel/fax:0086-539-8203336
