high pressure PET air compressor
- 5000 Set / Sets per Month
- Shanghai or Ningbo
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Piston | |
| Configuration | Stationary | Power Source | AC Power | |
| Lubrication Style | Lubricated | Mute | No | |
| Place of Origin | Jiangsu, China | Brand Name | HENGDA | |
| Model Number | WH-1.0/30SB | Voltage | 220v/380v/440v | |
| Certification | CE and ISO9001 | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
high pressure PET air compressor1)Model:WH-1.0/30SB
2)FAD:1.0m3/min
3)Pressure:30bars
4)Cooling method: air
high pressure PET air compressor
- high pressure air compressor for PET blow machine
The compressors under this series are widely used PET bottle blowing. - The compressor delivers outstanding quality under all weather conditions
- An automatic unload system to ensure that the system starts safely without residual pressure. This feature protect s both frame and motor and so extends the working life of all components.
- This equipment does not require a foundation saving plant installation costs.
Specification for high pressure air compressor
Model | Capacity M3/min | Working pressure Mpa | Motor KW | Speed rpm | Dimension mm | Weight KG |
VH-0.7/30-SB | 0.7 | 3.0 | 7.5 | 680 | 1240*630*780 | 310 |
WH-1.0/30-SB | 1.0 | 3.0 | 11 | 600 | 1470*780*885 | 430 |
WH-1.2/30-SB | 1.2 | 3.0 | 15 | 760 | 1470*780*885 | 450 |
WH-1.5/30-SB | 1.5 | 3.0 | 18.5 | 680 | 1530*765*1105 | 520 |
VH-0.65/35 | 0.65 | 3.5 | 9 | 800 | 1800*630*1400 | 420 |
VH-0.7/30 | 0.7 | 3.0 | 7.5 | 680 | 1800*630*1400 | 410 |
VH-1.0/30 | 1.0 | 3.0 | 11 | 600 | 2005*795*1260 | 550 |
WH-1.1/35 | 1.1 | 3.5 | 11 | 605 | 2005*795*1260 | 550 |
WH-1.2/30 | 1.2 | 3.0 | 15 | 760 | 2005*795*1260 | 550 |
WH-1.3/35 | 1.3 | 3.5 | 18.5 | 680 | 1140*735*1450 | 520 |
WH-1.5/30 | 1.5 | 3.0 | 18.5 | 680 | 1140*735*1450 | 520 |
2-WH-2.0/30 | 2.0 | 3.0 | 2*11 | 600 | 1880*1180*1440 | 1050 |
2-WH-2.2/35 | 2.2 | 3.5 | 2*15 | 605 | 1880*1180*1440 | 1080 |
2-WH-2.4/30 | 2.4 | 3.0 | 2*15 | 760 | 2050*1570*980 | 1080 |
2-WH-2.6/35 | 2.6 | 3.5 | 2*18.5 | 700 | 1880*1180*1440 | 1150 |
2-WH-3.0/30 | 3.0 | 3.0 | 2*18.5 | 760 | 1880*1180*1440 | 1150 |
3-WH-3.6/30 | 3.6 | 3.0 | 3*15 | 700 | 2350*1570*1880 | 1580 |
4-WH-5.0/3.5 | 5.0 | 3.5 | 4*18.5 | 680 | 2520*1920*1540 | 2400 |
4-WH-6.0/30 | 6.0 | 3.0 | 4*18.5 | 790 | 2520*1920*1540 | 2400 |
