2016 Hot Selling Copper Conductor 3 Core 4 Core Pvc Electric Cable
- Tianjin Xingang
- T/T Money Gram Credit Card PayPal
You May Like
-
Power Cables Types Copper Underground Electrical Power Cable
-
Various Types of Low Voltage Flexible Waterproof Pvc Insulated Power Cable
-
Copper Conductor 300 sq mm Electric XLPE/PVC Armoured Underground dc Power Copper Cable Price per Meter
-
3 Core Armoured Cable LV MV Power Cable With Copper Conductor PVC/XLPE Insulation SWA Armoured Power Cable
-
Manufacture Low Voltage Power Supply Cable Industrial Use 70mm2 Electric Cable Competitive Price
-
Copper Conductor 300 sq mm Electric XLPE/PVC Armoured Underground dc Power Copper Cable
Product Details
| Place of Origin | Hebei, China | Brand Name | Ronghua | |
| Model Number | PVC Cable | Insulation Material | XLPE | |
| Type | Other, 0.6/1kv | Application | Other, construction, underground | |
| Conductor Material | Copper | Jacket | PVC |
Product Description
2016 hot selling copper conductor 3 core 4 core pvc electric cable
Hebei Ronghua Wire Cable Co,.LTD-- 2016 hot selling copper conductor 3 core 4 core pvc electric cable
Low voltage cooper conductor XLPE insulated PVC flexible armoured pvc electric cable
1.The applications: Rated voltage (U0/U) 0.6/1kv 8.7/15KV 26/35kV in transmission & transformation line & for water-proofing purpose .
2. Cores: 1~5 cores,3C+1E,4C+1E,3C+2E
3. Product Features:
- No necessary to heat up in advance while installing above 0oC.
- Max. continuous normal operating Temperature: 90oC (PVC Sheathed cable).
- Max. Permissible temperature at short circuit (5s. at longest): 250oC.
- Permissible bending radius: Single core: ≥20(d+D)±5%. Three-core:≥15(d+D)±5%(D is the actual overall diameter of cable, and d is the actual overall diameter of conductor).
4.Model and Data
low voltage cooper conductor XLPE insulated PVC sheathed electric power cable
| U0/Um(kv) | 1st class | 0.6/1kv | 1.8/3kv | 3.6/6kv | 6/10kv | 8.7/15kv | 12/20kv | 18/30kv | 21/35kv |
| No.of Core | |||||||||
| 1 Core | Sectrion | 1.5-800 | 25-800 | 25-800 | 35-800 | 50-800 | 50-800 | 50-800 | 50-800 |
| area(mm2) | |||||||||
| 2 Core | Section | 1.5-185 | / | / | / | / | / | / | / |
| Area(mm2) | |||||||||
| 3 Core | 1.5-400 | 25-400 | 25-400 | 25-400 | 35-400 | 50-400 | 50-400 | 50-400 | / |
| 4 Core | Section | 2.5-400 | 2.5-400 | / | / | / | / | / | / |
| Area(mm2) |
4 cores:
| Cross Section mm2 | Insulated thickness mm | Sheath thickness mm | Outer diameter mm | Testing Voltage kv | Current loading capacity | |
| in the air | to be laid underground | |||||
| 1.5 | 0.7 | 1.5 | 10.6 | 3.5 | 21 | 25 |
| 2.5 | 0.7 | 1.5 | 11.5 | 3.5 | 28 | 33 |
| 4 | 0.7 | 1.5 | 12.8 | 3.5 | 37 | 44 |
| 6 | 0.7 | 1.5 | 14 | 3.5 | 46 | 54 |
| 10 | 0.7 | 1.5 | 15.9 | 3.5 | 63 | 73 |
| 16 | 0.7 | 2 | 19.1 | 3.5 | 84 | 94 |
| 25 | 0.9 | 2 | 22.7 | 3.5 | 109 | 120 |
| 35 | 0.9 | 2 | 25.4 | 3.5 | 132 | 144 |
| 50 | 1 | 2 | 29 | 3.5 | 159 | 169 |
| 70 | 1.1 | 2 | 32.9 | 3.5 | 195 | 205 |
| 95 | 1.1 | 2.5 | 37.7 | 3.5 | 237 | 245 |
| 120 | 1.2 | 2.5 | 41.6 | 3.5 | 273 | 278 |
| 150 | 1.4 | 3 | 47.6 | 3.5 | 310 | 309 |
| 185 | 1.6 | 3 | 50.6 | 3.5 | 355 | 347 |
| 240 | 1.7 | 3 | 56.4 | 3.5 | 416 | 399 |
| 300 | 1.8 | 3.5 | 62.2 | 3.5 | 473 | 446 |
| 400 | 2 | 3.5 | 68.9 | 3.5 | 512 | 431 |
Hebei Ronghua Wire And Cable Co.,LTD. is a spcialized manufacture of cables.
Welcome Your Visit! Hope to Get in Touch with You! | |
Cable Factory Name | Hebei Ronghua Wire And Cable Co.,LTD. |
Factory Established in | Year 1984, 30 Years’ Experience of Producing kinds of Cables |
Factory Location | Shaheqiao Town, Hejian City, Hebei, China |
Export Office Location | Aobei Park, Fengshou Road, Shijiazhuang, Hebei, China |
Cable Products Type | Electrical Wires |
Customized Cables per Requirement | |
Overhead Aluminum Aerial Bundle Cable (ABC Cable) | |
Flexible Rubber Cable | |
Mining cable, welding cable, waterproof Submersible pump cable | |
High Temperature Cable, Silicone Rubber Insulated Cable | |
Fire Resistant/ Flame Retardant Power Cable | |
Low Voltage Power Cable and Medium Voltage Power Cable with or without Armour (Armour Type: Steel Tape or Steel Wire) | |
1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.
2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, Hebei,Province, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3. Q: What is your sample policy?
A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.
4. Q: I am very interested in your product, can you sent me your full catalog and pricing list?
A: We can select some popular products for you immediately. Please let us know your requirements so that we can send out the quotation to you.
Welcome your inquiries of pvc electric cable ! We will reply within 12 hours!
Email: amy@
Skype: you580231
Whatsapp:86-15831928466
