automatic paper and plastic film slitting machine china
- Ningbo port shanghai port
- T/T Credit Card PayPal
You May Like
-
Printing Paper Jumbo Roll Slitting Machine
Quality Choice
-
Double Station Wrapping Paper Slitting Machine
-
PLC Controlled Slitting Rewinder Type High speed rewinder slitter machine
-
best price rewinding and cutting machine
-
Professional Thermal Paper Roll Slitting Machine
-
plastic pe sex film rewinding machine
Product Details
| Condition | New | Application | Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles | |
| Packaging Type | Bags, Film, Foil | Packaging Material | Paper, Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 220V/380V | Power | 3.7KW | |
| Place of Origin | Zhejiang, China | Brand Name | JINGDIANRUIHUA | |
| Model Number | LFQ-1100 | Weight | 1600KG | |
| Dimension(L*W*H) | 2500*1570*1530mm | Certification | CE/ ISO900O /SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
LFQ-B Series Vertical paper roller and film roller slitting machine china
Application: This machine is suitable for slitting and rewinding such various
roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. and
can cut edge, separate and cut material according to different requirements during production.
Performance and Features:
1. This machine is a kind of vertical slitting & rewinding machine
2. Independent master control panel, more flexible and even easier operation.
3. Automatic EPC for unwinding, photocell is suitable for tracking the edge and color of transparent material. 4. Air inflatable shaft for unwinding, automatic tension controller and magnetic powder brake for unwinding tension control
5. Double cam shaft for rewinding, Magnetic clutch control for rewinding tension control
6. Main motor with frequency converter for speed regulation
7. Equipped with rim charge conveying device
8. Automatic meter counting device
Type | FQ-L700B | FQ-L1100B | FQ-L1300B |
Max. Width of Mother Roll | 700mm | 1100mm | 1300m |
MAX .Diameter of Mother Roll | 600mm | 600mm | 600mm |
Width of Final Roll | 700mm | 700mm | 700mm |
Rewinding diameter | 450mm | 450mm | 450mm |
Slitting width | 30~600mm | 30~1000mm | 30~1200mm |
Slitting and Rewinding Speed | 5~180m/min | 5~180m/min | 5~180m/min |
Tolerance of EPC | <±0.5mm | <±0.5mm | <±0.5mm |
Total Power | 2.9Kw | 3.7Kw | 3.7Kw |
Weight of Machine | 1300kg | 1600kg | 1900kg |
Overall Dimension | 2100×1570×1530mm | 2500×1570×1530mm | 2700×1570×1530mm. |
