HJMTC CNC DRY BAR-TYPED INSULATOR BLANK PROCESSING MACHINE
- 20 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | HJMTC | |
| Model Number | GX43*2100 |
Product Description
Specifications
This machine is specially designed for electrical ceramics industry to process high voltage electrical ceramics insulator.1. This machine is specially designed for electrical ceramics industry to process high voltage electrical ceramics insulator. The machine body is made of high strength cast iron with characteristic of rigidity and shock absorption. Employing hardened steel, the worktable surfaces have good wear ability and long service life. The smooth and reliable operation of the machine ensures dimensional stability and low occurrence of fracture of blanks.
2. By embedding PC104 into the CNC control system, an integrated system with control system, LCD panel, operation panel in combination is provided for compact size and easy installation.
3. The machine has reverse backlash compensation and pitch error correction function.
4. USB port and RS232 port are available.
5. User friendly NC operation interface, English menu, alarm function are also characteristics of the machine.
6. Because of above designs, the machine is easily operated.
HJMTC CNC DRY BAR-TYPED INSULATOR BLANK PROCESSING MACHINE | |||||
SPECIFICATION | |||||
Model | GX43×2100 | GX53×2500 | GX60×3500 | ||
MAX. Diameter | 100~430 mm | 120~530 mm | 140~600 mm | ||
MAX. Height to be processed | 1200~2100 mm | 1200~2500 mm | 1200~3500 mm | ||
Rotation Speed Of | 0~500r/min | 0~500r/min | 0~500r/min | ||
Max. Traverse Speed
| Axis X | 5000 mm /min | 5000 mm /min | 5000 mm /min | |
Axis Z | 6000 mm/min | 6000 mm/min | 6000 mm/min | ||
Traverse
| Axis X | 300 mm | 350 mm | 400 mm | |
Axis Z | 2200 mm | 2600 mm | 3600 mm | ||
Center of tailstock | 300 mm | 300 mm | 300 mm | ||
Feeding Speed | Axis X | 300 mm/min | 300 mm/min | 300 mm/min | |
Axis Z | 500 mm/min | 500 mm/min | 500 mm/min | ||
Resolution | Axis X | 0.001 mm | 0.001 mm | 0.001 mm | |
Axis Z | 0.001 mm | 0.001 mm | 0.001 mm | ||
Positioning Accuracy | Axis X | 0.03 mm | 0.03 mm | 0.03 mm | |
Axis Z | 0.05 mm | 0.05 mm | 0.05 mm | ||
Machine Dimension (L×W×H) | 2240×1680×4670 mm | 2240×1680×4670 mm | 2240×1680×4670 mm | ||
Machine | approx. 6000Kg | approx. 7000Kg | approx. 9500Kg | ||
