TOP UP Saddle Clip with Anchor Insert clip for Building equipment

Specifications

•Clip USA
16-32mm diameter; withstands up to 4kg
Use on covered resin tubing, sheathed pipes, drain hoses, combined ducts, plastic flexible conduits, and flexible gas lines
Plug length: 25mm Standard type Compatible with reinforced and half precast concrete
After attaching, the upper cover can be lifted out in order to remove only a part

• Features
1: Easy to use: requires just a 6mm bit
2: Fast: Just use your finger to insert the one-push saddle
3: Won't loosen: There is no need to affix a curl, anchor, or pin
* Plug can pull weights of over 20kg
4: Convenient: use 2-3 sizes simultaneously
* No need for special saddles for each caliber part! Can be attached and removed at will. Reusable!
* Depending on the material, some plugs may not be changed once inserted.

• Compatible materials
Reinforced concrete/autoclaved lightweight concrete/half precast concrete/siding/extruded cement panels/Spancrete/deck plates/brick/blocks/stone/wood
* Incompatible with: steel, plasterboard, plywood
* ALC pulling weight is half the standard at 10kg

• Materials: Anti-ultraviolet treated polypropylene

• Use: One-push type, insert tightly up to the clip neck

• The wide variety lets you choose the right one for the job
1) Hygienic equipment: Covered resin tubing and sheathed pipes
2) Disaster prevention: Construction objects such as resin pipes.
3) Gas lines: Flexible gas lines and sheathed pipes
4) Cables, combined ducts, and plastic flexible conduits (layered ceiling materials)
