Product Details
| Place of Origin | Shandong, China | Brand Name | JQLASER | |
| Model Number | JQ-50 | Rated Power | 1.6KW | |
| Engraving Speed | 8000mm/s Max | Main Axle Rotational Speed | N/A | |
| Feeding Height | N/A | Milling Cutter Diameter | N/A | |
| Application | Metal engraving and marking | Dimensions | 110mmx110mm | |
| Weight | 240kg | Certification | CE & FDA |
Woodencase or customizable.
Product Description
1. Product description:
JQ Diode side-pump laser marking machine is the new product developed by JQ laser company, it is updated product of YAG laser marking machine. It adopts the most advanced laser technology in the world and the imported diode laser arrays. The 808nm laser diode pumping Nd:YAG mediums produce quantity of antiparticles, which will cause 1064nm high power laser pulse output under the function of Q switch. The beam quality is very good and the line is rather nice. For the convenience of our customers, we have improved the machine structure. The optical system uses the fully sealed structure. It looks more beautiful and easy to operate. Not only can it work alone, but also cooperate with other equipments in production line.
2. Machine features:
(1) The size of JQ diode side-pump laser marking machine is small. The volume is only 1/4 of the traditional lamp pump laser.
(2) The optical system uses the fully sealed structure to prevent the dust entering laser body and reduces the equipment failure rate.
(3) The machine is able to preview the light path and point out the focus, which are very convenient for the materials that will be processed to be located.
(4) This machine provides the precise three dimension worktable and newest outside water-cooling system. The cooling system can control the water temperature very accurately, which ensures the long time working. The machine movement noise is extremely low.
(5) The software owns intellectual property rights. It is compatible with file formats saved by CORELDRAW, AUTOCAD, PHOTOSHOP and software. It can mark auto-code, sequence number, bath number, date, bar code, etc.
Metal logo laser marking machine
YAG laser marker
laser engraver on sale
laser marking machine
3. Product Parameters
Model | JQ-50 | |
Laser device | YAG, 50-watt laser power | |
Laser Wavelength | 1064nm | |
Cooling System | Water cooling (water chiller) | |
Beam Quality | m2<6 | |
Laser Repetition Frequency | ≤50KHz | |
Marking Area | 100mm x 100mm (optional: 200mm x 200mm) | |
Packing size | 1400mm x 1400mm x 1500mm | |
Marking Depth | ≤0.3mm | |
|
| The depth is adjustable according to different materials. |
Linear Speed | ≤7000mm/s | |
Min. Line Width | 0.02mm | |
Min. Letter | 0.25mm | |
Repeatable Accuracy | ±0.001mm | |
Gross Power | ≤2.5KW | |
Electricity Source | 220V/50Hz/15A | |
4. Applicable Materials industries:
Electronics industry, communication, electrical equipment, clock and watch, glass, jewelry, dress and personal adornment, etc.
5. Sample
Please don't hesited to reach me if any question.
Our product could also be customizable about laser power, size, color. etc.
