RP601J /701J asphalt concrete paver
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | XCMG | Model Number | RP601J /701J |
Product Description
Specifications
The multi-functional RP601J or RP701J asphalt concrete paver is developed
With water-cooled, turbo-charged engine, typed YC6108G, made by YUCHAI Engine Group, The strong power, high reliability, high anti-heat performance, power compensation for tableland area make it widely used.
Large capacity clutch typed EQ1141G and automobile gear-box both made by DONGFENG automobile Group make the adequate torque storage of transmission system.
High performance electrical and hydraulic components ensure the machine has reliable working system.
The parts that could be easily worm such as auger blades and bottom plate of the conveyor system and the screed are made of imported anti-friction materials.
Reasonable structure arrangement, large contact surface of the crawler system ensure the safe and reliable work even at the hard work conditions.
Central lubrication system supply the lubricant to the bearing of high temperature parts, lessen the work of maintenance.
Automatic material conveying and spreading give the equality of material supply.
Auto-leveling system consists of two grade sensors and one slope sensor improves the pavement smoothness.
Item | unit | parameter |
Basic working width | m | 2.5 |
Max, working width | m | 6.0/7.0 |
Max. paving thickness | mm | 300 |
Paving speed | M/min | 2.0-5.98 |
Traveling speed | Km/h | 1.52-4.55 |
Theoretical productivity | T/h | 400 |
Hopper capacity | T | 13 |
Gradient ability | % | 20 |
Smoothness | mm/3m | 3 |
Slope leveling tolerance | % | ±0.03 |
Crown adjust | % | 0-+3 |
Tamper amplitude | r/min | 0-1500 |
Tamper amplitude | mm | 4 |
Engine type |
| YC6108G |
Rated power | KW | 92 |
Rated revolution | rpm | 2300 |
Weight | t | 16-19 |
Overall dimension | mm | 5897×2580×3629 |
