Concrete Mixer Truck

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	Sino truck	Model Number	HOWO
After-sales Service Provided	Engineers available to service machinery overseas

Concrete Mixer Truck
1. Dimension: L*W*H: 9970*2495*3790mm
2. Load: 15000kg
3. Full load: 30530kg
4. Mix volume: 7/10cbm

Concrete Mixer Truck

MAIN DESCRIPTION
Overall Dimensions	8810mm2490mm3800mm(LWH)
Tare Weight	11180kg	Payload	17500kg
Front Overhang	1500mm	Rear Overhang	2335mm
Wheelbase	3625mm+1350mm	Track (F/R)	2022mm/1830mm
CHASSIS
Chassis Brand	SINOTRUK HOWO
Chassis Model	ZZ1257M3641, driving type 6x4
Cab	Standard HW70, left hand drive, air-conditioner, no sleeper
Engine	SINOTRUK WD615.87, 290hp, Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L
Gear Box	FULLER9, No. of speeds: 9 forward & 1 reverse
Traversing Mechanism	German ZF8098, turning system pressure 18MPa
Clutch	GF420J, Single-plate dry clutch
Rear Axle	ST16 tandem axle, rated load 2x13ton, ratio 5.73
Wheels and tires	Rim 8.5-20; tire 12.00-20, 10 units; Spare wheel carrier: with one spare wheel
