PVC Half-crust Foam Board Production Line plastic machine Quality Choice Most Popular

Specifications

1.Pvc board machine adopts specially designed SJSZ80/156 or SJSZ92/188 conical twin screw extruder and imported ABB orSiemens speed frequency converter.It chooses imported RKC and Omron temperature controller. It have a very good plasticization performance.
2.This Machine can produce pvc products of different specifications only via changing mould.
3. Pvc board machine also include the die head, cooling calibrating mould, cooling carrying roller,hauling-off unit, edge trimming device,dust collecting machine,cutting device,and delivery stacker.
4.All the eletrical parts in line are from famous brand supplier,SIEMENS &ABB brand,insure the machine can high stable running.The machine also have the features of high automatic,easy operate etc.
5.The auxiliary units are able to use the PLC control, which is stable and reliable.
6.The foam boards is mostly used in transportation , advertisement,construction furniture industry ect.
7. The board thickness is from 3mm to 35mm,width is from 1220mm to 1580mm.

Application

Transportation: such as steamship, aeroplane, carriage, traine compartment, roof shed, case core layer, inner upholster, etc.
Architecture: such as building wall board, decoration board, housing, office, public building interlayer, commercial decoration shelf, non-dust room board, ceiling plate, etc.
Advertisement: such as screen printing, computer lettering, ad board, etc.
Industry: such as chemical industry antisepticizing project, thermoforming, for refrigeratroy, for temperature keeping, for environment protection, etc.
Other applications: such as mould plate, sports equipment, breeding equipment, seashore wet-proof facility, water-fast material, art material, various interlayer, etc.

Production Flow

Raw materials---Mixing---Feeding---Extruding---Molding---Calibrating---Haulling off---Cutting---Stacking---Printing or Hot stamping---Package.

Main Composition Of  PVC Foaming Board Machine

Auxiliary machine

Production Line

Conical twin screw extruder

ABB frequency converter, SIEMENS contactor, RKC Japan, Motor power:75KW

Calibration unit

calibration plate:1500mm×500mm 4couples

Cooling tank

length:6000mm

trimming knife:3 sets

Haul off unit
8 couples

cylinder clamping and loosening

Cutter

Payment term:

1)30% of total amount paid by TT as advance.

2)after the machine is finished ,buyer come to test the machine in seller’s factory

and then pay the 70% balance by TT or irrevocable L/C at sight , then seller ship the machine.

 Qingdao Chinese Science Machinery Co.,Ltd

Telephone: 86-0532-83726364
Mobile Phone:15192790706
Fax: 86-0532-84873001
Address: No. 7 Wenzhou Road, a -27
Zip:266032
Country/Region:China (Mainland)
Province/State:Shandong
City:Qingdao
Welcome standard-product inquiry, Welcome OEM inquiry
