Popular Vibrating Screen Mesh
- Tianjin Qingdao Port
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Type | Other, Circular, vibrating screen | |||
| Application | Ore | Place of Origin | Henan, China | |
| Brand Name | DSM | Model Number | A variety of models | |
| Power(W) | 11 | Dimension(L*W*H) | 700*1200 | |
| Certification | ISO9001:2000, ISO9001:2000 |
Product Description
Specifications
vibrating screen mesh1.long flowing line
2.many screening specification
3.strong violent vibration force
vibrating screen mesh
Main Features of vibrating screen mesh
1. This series of vibrating screens use eccentric block to produce strong exciting force.
2. Crossbeam and the main body of the vibrating screen are connected with high strength screw bolts. So our vibrating screens have the features of simple structure and easy maintenance.
3. The vibrating screen adopts tire coupling with capability of flexible connection and stable operation.
4. Xuanshi's vibrating screens adopt the structure of small amplitude, high frequency, large obliquity to make the screen hold the capability of high efficiency, large handling capacity, long life span, low consumption, and little noise; you will find this series of vibrating screen optimized for your demands.
Technical Specification of vibrating screen mesh
Type | Layers | Sieve Pore | Screen Spec (mm) | Max. Feed Size (mm) | Capacity(t/h) | Oscillation frequency | Double-amplitude | Power of motor |
2YA1236 | 2 | 3~50 | 1200x3600 | 200 | 15~160 | 970 | 5~9 | 11 |
2YA1548 | 2 | 3~80 | 1500x4800 | 400 | 50~250 | 970 | 5~9 | 15 |
3YA1548 | 3 | 3~80 | 1500x4800 | 400 | 50~250 | 970 | 5~9 | 15 |
2YA1848 | 2 | 3~80 | 1800x4800 | 400 | 50~300 | 970 | 5~9 | 18.5 |
3YA1848 | 3 | 3~80 | 1800x4800 | 400 | 50~300 | 970 | 5~9 | 18.5 |
2YA1860 | 2 | 3~100 | 1800x6000 | 400 | 50~350 | 970 | 5~9 | 22 |
3YA1860 | 3 | 3~100 | 1800x6000 | 400 | 50~350 | 970 | 5~9 | 22 |
2YA2160 | 2 | 3~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 |
3YA2160 | 2 | 3~100 | 2100x6000 | 400 | 100~500 | 730 | 6~8 | 30 |
