Hot! Monel 400 Pipe
- Xi'an/Tianjin/Shanghai/Hong Kong
 - T/T D/P D/A Credit Card

You May Like
Product Details
| Place of Origin | Shaanxi, China | Type | Nickel Pipe | |
| Application | chemistry,petrochemistry,ocean exploration | Grade | Nickel.Copper | |
| Ni (Min) | 62% | Powder Or Not | Not Powder | |
| Model Number | Monel 400 | Brand Name | GETWICK |
Product Description
Specifications
Monel 400 Pipe1.material:Ni200,Ni201,monel, inconel
2.Standard:ASTM B161,ASTM B163
3.Certificate:ISO9001:2008 certificat
Alloy  | %  | Ni  | Cu  | Fe  | C  | Mn  | Si  | S  |
Monel400  | Min.  | 63  | 28  | |||||
Max.  | 34  | 2.5  | 0.3  | 2  | 0.5  | 0.024  |
Density  | 8.83 g/cm³  |
Melting point  | 1300-1390 °C  |
Alloy state  | Tensile strength Rm N/mm²  | Yield strength R P0. 2 N/mm²  | Elongation A 5 %  |
Monel400  | 480  | 170  | 35  |
Monel 400 alloy in the fluoride gas, hydrochloric acid, sulfuric acid, hydrofluoric acid and their derivatives have a very good corrosion resistance property, and possess better corrosion resistance more than the copper alloy in the sea water. Acid medium: Monel 400 have corrosion resistance in less than 85% consistency of sulfuric acid. Monel 400 is an important material that resistant to hydrofluoric acid. Water corrosion: Monel 400 alloy in most corrosion cases of water, not only excellent corrosion resistance, but also less pitting, stress corrosion, the corrosion rate less than 0.025mm / a. High temperature corrosion: Monel 400 for the work of the highest temperature at about 600 °C in general in the air, in the high temperature steam, the corrosion rate less than 0.026mm / a. Ammonia: Monel 400 can be resistant to an hydrous ammonia and aminate conditions corrosion below 585 °C due to the high nickel.
Application field
Monel 400 alloy is a multi-purpose material in many industrial applications:
1. Seamless water pipe in the power factory
2. Sea-water exchanger and evaporator
3. Sulfuric acid and hydrochloric acid environment
4. Crude distillation
5. Sea-water in the use of equipment and propeller shaft
6. Nuclear industry and used in the manufacture of uranium enrichment isotope separation equipment
7. Manufacturing hydrochloric acid equipment used in the production of pump and valve
