Lab 1200C Three Zone Tube Annealing Furnace
- QINGDAO TIANJIN SHANGHAI
- T/T PayPal
You May Like
-
1200C Single Heating Zone Tilting Rotary Furnace for Heat Treatment
-
LCD Touch Screen/PC Interface 1200C Portable Electric Furnace
-
1700 C Atmosphere Controlled High Precision Tube Furnace
-
2015 New 3 Zone Multi-function Lab Electric Tube Furnace/CVD Electric Furnace
-
1700 C Laboratory Small Metal Annealing Furnace
-
1200c Mini Desktop Furnace for Lab
Product Details
| Brand Name | CY | Model Number | CY-O1200-IIIC |
Product Description
lab 1200 C three zone tube annealing furnace
Application of tube annealing furnace
1.CVD experiment
2.Preparation of carbon nanotubes
3.Growth of graphene
4.Crystalline silicon substrate coating
5.Diffusion welding for metal materials
6.Heat treatment under the vacuum of atmosphere surroundings
Features of tube annealing furnace
1.Fast heating rate:20°c/min
2.Multi-function: CVD experiment, growth of graphene, crystalline silicon substrate coating and etc
3.three heating zone.
4.50 steps programmable automatic control
5.Can connect with vacuum pump and atmosphere furnace.
6.Accept PC interface control
Technical parameters of tube annealing furnace
| Model | CY-O1200-IIIC |
| Display | LED |
| Chamber material | imported fiber |
| Heating element | imported alloy heating wire |
| Max.temperature | 1200℃ |
| Working temperature | ≤1150℃ |
| Heating rate | ≤20°c/min |
| Heating zone | Three |
| Temperature zone length | 220+440+220mm |
| Thermostatic zone length | 100+200+100mm |
| Tube Material | high purity quartz |
| Tube Size | 50mm 60mm 80mm 100mm 1200mm |
| Tube length | 1200mm 1400mm |
| Flange connection | stainless steel flange |
| Control mode | PID automatic control via SCR power control |
| Temperature accuracy | ±1℃ |
| Working voltage | AC 220V 50-60Hz |
| Main power | 5kw |
| Packing | PLYwood box |
| Thermal couple | K type |
| Accessories | quartz tube 1pc, flange 1set, plug 4pcs,O-rings 8pcs, glove 1pair, alumina crucible 1set, furnace hook 1pc, manual book |
Picture of tube annealing furnace
Packaging of three zone tube furnace
PLY wood box as below picture, or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
