High Precision Atmosphere Controlled Single Zone Electric Furnace Machine
- QINGDAO TIANJIN SHANGHAI
- T/T PayPal
You May Like
Product Details
| Brand Name | CY | Model Number | CY-T1700-60IC |
Product Description
high precision atmosphere controlled single zone electric furnace machine
Application of electric furnace machine
1.CVD experiment
2.Preparation of carbon nanotubes
3.Growth of graphene
4.Crystalline silicon substrate coating
5.Diffusion welding for metal materials
6.Heat treatment under the vacuum of atmosphere surroundings
Features of electric furnace machine
1.Fast heating rate:20°c/min
2.Multi-function: CVD experiment, growth of graphene, crystalline silicon substrate coating and etc
3.LED high light display
4.50 steps programmable automatic control
5.Can connect with vacuum pump and atmosphere furnace.
6.Accept PC interface control
Technical parameters of electric furnace machine
| Model | CY-T1700-60IC |
| Display | LCD touch screen |
| Chamber material | imported fiber |
| Heating element | imported alloy heating wire |
| Max.temperature | 1700℃ |
| Working temperature | ≤1600℃ |
| Heating rate | ≤20°c/min |
| Heating zone | Single |
| Temperature zone length | 300mm |
| Thermostatic zone length | 150mm |
| Tube Material | high purity corundum |
| Tube Size | 100mm 80mm 60mm 50mm for option |
| Tube length | 1000mm |
| Flange connection | stainless steel flange |
| Control mode | PID automatic control via SCR power control |
| Temperature accuracy | ±1℃ |
| Working voltage | AC 220V 50-60Hz |
| Main power | 4.5kw |
| Packing | PLYwood box |
| Thermal couple | B type |
| Accessories | corundum tube 1pc, flange 1set, plug 4pcs,O-rings 8pcs, glove 1pair, alumina crucible 1set, furnace hook 1pc, manual book |
Picture of electric furnace machine
Packaging of electric furnace machine
PLY wood box as below picture, or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
