Home > Products > graphene growth system > 4 Gas Way Good Quality Graphene Growth System With Mass Flow Metre
4 Gas Way Good Quality Graphene Growth System With Mass Flow Metre
Negotiable
/ Set
1 Set(Min. Order)
- Zhengzhou QingdaoTianjin Beijing Ningbo etc.
- T/T D/P D/A Credit Card
You May Like
-
Single Crystal Grower System/growing Furnace With Vacuum Chamber for Oxide Single Crystals
-
Good Quality Single Crystal Grower System for Sale
-
Good Quality Cubic Zirconia Single Crystal Grower System With Vaccum Pump for Sale
-
Good Quality Cubic Zirconia Single Crystal Growing Furnace With Vaccum Pump for Sale
-
Cubic Zirconia Single Crystal Growing Furnacefor Oxide Single Crystals Upto 2100C
-
Cubic Zirconia Single Crystal Growing Furnace for Sale
Product Details
| Brand Name | CYKY | Model Number | CY-O1200-60-4CLV-PE | |
| Place of Origin | Henan, China |
Product Description
4 gas way good quality graphene growth system with mass flow metre
Product Description
Featrues of graphene growth system
1.Lower temperature processing compared to conventional CVD.
2.Film stress can be controlled by high/low frequency mixing techniques.
3.Control over stoichiometry via process conditions.
4.Offers a wide range of material deposition, including SiOx, SiNx, SiOxNy and
Amorphous silicon (a-Si:H) deposition.
Technical parmaters of graphene growth system
| Plit Tube furnace | Input power: 208 – 240V AC, 1.2kW 1200°C Max. working temperature for < 60 minutes 1100°C Max for continuous heating High purity quartz tube 2"OD x 1.7"ID x 39.4" Length 30 segments programmable precision digital temperature controller 8" (200mm), single zone. 2.3" (60mm) (+/-1°C) @ 1000°C |
| Plasma RF Generator | Output Power:5 -300W adjustable with ± 1% stability RF frequency: 13.56 MHz ±0.005% stability Reflection Power: 200W max. Matching: Automatic RF Output Port: 50 Ω, N-type, female Noise: <50 dB. Cooling: Air cooling. Power : 208-240VAC, 50/60Hz |
| Vacuum Flange and Fittings | Vacuum flange set is made of stainless steel 304. Left flange assembly includes a KF-25 vacuum port, two KF-25 quick clamp, A KF-25 right angle valve, a KF-25 vacuum bellows, a flange Support 1/4 O.D Hose fitting, and a needle valve. Right flange assembly includes a digital pirani gauge, 1/4 O.D tube fitting, 1/4" Feedthrough and a needle valve. |
| Vacuum Pump | AC 220V 50 Hz 1/2HP 375W 2 Liter /S or 120 liter/m Oil trap (inlet) and exhaust filter (outlet) are installed. Max. vacuum: 10-2 torr |
| Warranty | 12 month (exclusive wearing part) |
Pictures show of graphene growth system
Packaging & Shipping
Packaging of graphene growth system
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Our Services
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
Company Information
Factory show
Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Independence and innovation is the company's tenet.
Contact Information
Name:Jane Rao
skypeID:raojane999
qq:2542331489
tel:8618134414225
Web site:
We are looking forward your order of graphene growth system
