GIGA LXC High quality Automatic Feeding For Gluing machine

Specifications

 LX-AFH2 Auto corrugated cardboard feeder for carton

High quality Auto Feeder

Gluing machine

1. Max paperboard size:   900 X 2400 mm
2. Paperboard stacking height :  1800 mm
3. Max. stacking weight:    2000 Kg
4. Paperboard lifting type, Fork lifted by chain
5. Power of fork rotating,Hydraulic driving
6. Lifting power of horizontal conveyor  Hydraulic driving
7. The LX-AFH2 auto feeder can be moved lengthwise.
8. Carton feeder height between clap paper down and ground 1200mm
9. Corrugated cardboard feeder machine roller is ground fixed type
10. Fork push cardboard feeding automatically
11. The whole equipment can work with carton machinery Synchronously.
12. Transmission in side has side baffle ,electric-adjust telescopic.
13. Front of the conveyor belt has automatic lengthwise clap paper device(suit with printing machine clap enter and exit), down part has down limit.
14. Level conveyor belt can auto-control feeding (printing machine photoelectric control
     ), frequency control
15. Chain push cardboard up by rocker-type limit switch(or photoelectricity), carton feeder, carton making machine and carton machinery and auto sheet feeder for carton in good quality.

3-4         High quality Auto Feeder For Gluing machine
