GIGA LX corrugated carton box folder gluer machine

Specifications

LX-FG Automatic Carton Folding and Gluing Machine Inline With Carton Machine

Carton folder gluer machine is full computerized

corrugated carton box folder gluer machine

1. Touch screen input order, automatic adjust specifications.
2. Lateral scorer to facilitate folding.
3. Vacuum suction belt transmission to prevent slipping, and avoid scissors movement.
4. Both sides equipped with guiding rollers.
5. Imported USA VALCO glue spraying system, automatic non-contact tracking, and accurate coating.
6. Carton strapping machine moving parts are composed of imported ball screw and linear guides track;
7. Stacker and output are controlled by servo motor, max.speed 300 sheet/min.
8. Work independently or equipped with printer & slotter machine.
9. Max.machine speed: 300sheet/min.
10. Max.feeding size: 2500*1600mm
11. Min.feeding size: 650*400mm
12. Main motor power: 22kw
13. Total power: 50.8kw
14. Dimension: 12000*4810*2530mm
15. Total weight: 20 ton

We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for boxing machine LX308N, LX-608CN LX707N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department. better and better quality.
