WB2003 Double Wire Forming Machine factory manufacturing

Our twin loop wire forming machine produces double wire of a wide range of diameters and
different pitches, using nylon-coated wire from spools.

The wire is unwound from a spool, straightened and smoothed by the special rectifying
tools of the machine and then is guided via guide rollers into the forming unit where
the wire is formed into zigzag carpet and further to C shape profile the double
wire loops formed. The endless double wire connected from the forming machine,
via the connecting table to the spooling machine. The connecting table is to
"sense" the length of the formed double wire loops and to control the spooling
machine when and how fast to wind. The spooling machine is for winding the endless
double wire onto spools automatically. An endless paper strip which has edge-cut
is simultaneously wound on in order to separate the loops.

Data:
1) Basic equipment: one diameter in the range of pitch 3:1, or one diameter in the
range of pitch 2:1
2) Sizes available: by changing the matched size-tools, the machine can be adjusted
to additional diameters in the range of pitch 3:1 or 2:1
3) Wire consumption: nylon-coated wire from spools
4) Electrical equipment: 220V, 1-phase, 50/60Hz, 0.75kW, other voltage available
upon request
5) Required space: 3.50 x 1.00m, including wire spool
6) Weight: 350kg, not including wire spool
