Best Quality Oil Water Separator Prices
- QINGDAO
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | EPO |
Product Description
Specifications
product: oil water separatorgrease trap with CE and ISO9001:9002
Small occupying area
convenient install
suited wide
Best Quality oil water separator prices
Introduction:
The Full stainless steel high efficient no power oil-water separator is an environmental protection high newly product aiming at treating oily wastewater.Our company produces the oil-water separator by adopting several item environment protection technology,scientific treatment process and unique design,according to proportion difference between water and oil, made the oily particles floating on the water surface after several time’s subcritical flow and the baffle’s
collision. With characteristic of multilevel processing and separating unit, adopting the inclined board Oil separation technology and specific liquid level automatic control technology, no need any power and additive, which can separate the mix grease in oily wastewater automatically and centralize it to oil groove,discharge it out automatically, the oil content of the wastewater can reach national emission standard .
Operating principle:
Oily wastewater discharge into municipal drainage pipeline before treatment, will form "ditch oil", which will cause much influence to drainage equipment and municipal sewage treatment plant. Such equipment is make the oily wastewater in the action of gravity, with the help of oil water proportion difference, adopting nature flotation to separate and remove floating oil and parts of thin disperse oil,by unique devise the inner structure of oil-water separator without power, according to shallow pond sediment theory, apply different flow separation principle and turbulent variable laminar flow of the dialectical relationship, make the wastewater reduce flow rate, flow down, oil droplets floating when flow by oil-water separator.Practice prove, such product can make the removal rate of grain size above 60um floated oil above90%, the oily content of discharged sewage lower than the three level standard (100mg/L) of <sewage integration discharge standard>
Technics Processing:
Characteristic
(1)High technique content: adopting to shallow pond sediment theory and different flow separation principle and turbulent boundary layer theory, improve the separate surface of unit pond, great improve oil –water separation efficiency, short the wastewater retention time, reduce equipment volume, save occupy area and budget.
( 2) No need electricity,power, save expense: only using the liquid level difference when sewage flow by device, easy to realize the purpose of oil –water separation,by using unique technics principle and structure design, reliable work, small volume, long service life, no need add any agentia and drug, without second pollution.
(3) Easy installation and maintenance,, no need person to maintenance operation,only need discharge oil regular.
( 4) Apply to any kinds of oil, oil-taking concentration without any limit, can widely used in natural petroleum and petroleum products,oil tar and oil tar fraction,animal and plants oil and wool grease etc wastewater project, specialized using in catering industry oily wastewater treatment.
Application scope:
Widely used in hotel,restaurant,canteen ,food process factory etc animals ,plants oily wastewater treatment, also can apply to oil field ,petrochemical,ship,gas station,mechanical processing and coking etc contain mineral oil industrial sewage treatment, can match with other water treatment device.
Installation :
The catering industry oil-water separation can divide as underground and ground type.
a. if adopting underground type, the Civil foundation size is add 300-500mm in original equipment’s length and width ,height add 50-200mm,the detailed size can be decided according to the working condition. It should mortar 240mm width clay red brick in the base of oil-water separation ,access hole and around oil salvage mouth, with 1:2 cement mortar painted, cover plate adopt c20 concrete and 15cm thick precast slab.
b. if set on the ground, place it in the ground level then connect with the pipeline.
Appliaction area: used in dining hall,restaurant,hotel,fast food chains etc.
Matters need attention:
1.simple installation,convenience,only need connect inlet and outlet is ok
2,the sewage inlet must be install separate slag net, be sure to make the whole,oil-water separator in the same level, the first time using oil-water separator, its separate oil case should be inject enough clean water after installed it, then onnect 220V power. clear several times of separate slag case and separate oil case each day, ensure Water flow gently smooth and raise separate oil effect, must switch off power before clear it.
3. it need thorough clear the separate slag case and separate oil case each month at least 1 time, clear up the sediment and oil sludge, check the electronic control parts whether work normal , it need fill up clean water after clear.
Trade Term :
MOQ: 1 SET Loading Port: Qingdao
Delivery Term: 10 days from receive the Payment
Payment Terms: T/T, 100%,or 30% prepayment, 70% before deliver
Contact Us
- Qingdao Yimei Environment Project Co., Ltd.
- Contact namelin chen Chat Now
- Phone86-532-88180456
- AddressChang an Road, Jiaonan Qingdao, Qingdao, Shandong
