Dosing PE tank for RO system

Specifications

 Dosing PE tank for RO system

The PE mixing dosing tank is consisted of plastic tank and mixer for liquid, tank body, it is Rotomolding a molding tank which adopting imported PE raw material.

Preinstall metering pump and mixer installation site, mixer,dosing tank,metering pump three in one, convenient to use.

The product is tough, flexible, anti-impact and corrosion-resistant. The matching mixer is divided of direct stir and side stir, the direct mixer requires matched strengthening board and tanks, while the side mixer can be equip with fixed mount to improve its stir effect and tank body service life. The types of stirrer material is stainless steel

Advantage:

The product is tough, flexible, anti-impact and corrosion-resistant. The matching mixer is divided of direct stir and side stir, the direct mixer requires matched strengthening board and tanks, while the side mixer can be equip with fixed mount to improve its stir effect and tank body service life. The types of stirrer material is stainless steel.

Apply scope: in water treatment mainly used in all kinds of agentia

mixing,dissolve,storage, then pass by metering pump to dose solution .

projects .

Main components:

1.Metering pump
-Mechanical actuated diaphragm, no-leakage structure
-PVC,PTFE, PVDF,304,316 is available as the pump head material
-flow can be adjusted during operation, the range is   0.5~500L/h

Pressure range:0.2~1 Mpa
-Automatic  control who can accpet4~20mA is available (JWM-AD series)
-Motor: standard 220V/380V,50Hz

Regulating mode: manual / automatic

2.mixer

  Rated power :0.18~11kW;

 mixer diameter: 0.4~3m

mixing speed:60~200rpm

3.Solution tank

Material:PE,PVC

 Volume :1000L

Dosing Tank size: 40L/80L/100L/120L/180L/200L/300L/500L/1000L/20

00L/3000L/4000L/5000L

Mixer power: 0.18KW/0.37KW/0.55KW/0.75KW/1.1KW/1.5KW/2.2KW/3KW/4KW/5.5KW/7.5KW/11KW
