Automatic Chlorine Dioxide Generator/clo2 Generator for Disinfection

Qingdao)YM chlorine dioxide generator is a kind of chemical reaction, precision measurement, precise electronic control, closed loop monitoring system for the integration of precise and reliable high-tech products, the whole system is mainly composed of precision metering pump, reactor and traffic monitoring system, using the machine integration for the integration of integrated installation, so the structure is compact, easy installation, reliable performance, easy to maintain.

Second, the product features

1, which is produced with Chlorine dioxide is not stable on its physical characteristics cannot be mass storage. Chlorine dioxide must be generated on-site and field use. Reaction procedure is as follows: 4 HCL + 5 naclo2 nacl clo2 = 4clo2+ 5naclo2 + 2 h2o

2, the best security (Qingdao)YM chlorine dioxide generator is a safe and reliable automatic closed loop system, chemical reaction process is in a closed reactor and the dosing process is completed in the closed mixer, thus make the system to avoid the leakage. The whole system is equipped with a can ensure accurate, safe and o-phenylenediamine traffic monitors, at the same time also can detect water in bypass. Chemical medicine barrel equipped with a set of float switch, when the drug shortage can send out alarm signals in time. System also equipped with air line and residual liquid discharge line, ensure the safe and reliable operation

3, easy to operate Through the microprocessor to control the number of chlorine dioxide generator can be directly set on the dial. When equipment using automatic mode operation, dosing quantity can be set in advance, control the LCD display can provide current information such as chlorine dioxide generates and flows through the main pipe flow. In addition, chlorine dioxide device can also be according to the size of the processed water, through the measurement and control instrumentation automatic control its number.

4, remote display The number of chlorine dioxide by analog instrument transfer signals to the remote display terminal, when using the flow ratio control method in chlorine dioxide production, the main water pipe flow can also be used this way in the remote display.

5, high yield Qingdao) optimization of the reactor, with anticorrosive shell with separated metering pump and the monitor, can guarantee more than 90% of chlorine dioxide generates .

6, fast installation When all the parts in the factory is connected, but operation at any time, the set of device installed on the plastic frame body. If you need to bypass pump can be directly connected.
