carbonated soft drink filling 3 in 1 machine, cola filling machine
- 1000 Set / Sets per Month
- shanghai
- T/T Credit Card
You May Like
-
Soft Drink Filling Machine,carbonated drink plant, cola machine
-
12000bph Soft Drink Filling Machine,rotary filling machine,carbonated filling machine, cola filling machine
-
PET bottle CSD filling 3 in 1 machine
-
Soft Drink Filling Machine,rotary filling machine,carbonated filling machine, cola filling machin
-
automatic PE film thermal wrapper, automatic shrink packging machine, film packing machine, bottle packaging machine
-
Beverage machine,monoblock rinser filler capper machine
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Bottles | Packaging Material | Glass, Metal, Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Place of Origin | Jiangsu, China | Brand Name | HFJX | |
| Model Number | DXGF | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
The machine combines washing/filling/capping in one machine with complete automation. The filling process adopts the micro-pressure technology, which makes filling process faster and more stable. The productivity can be from 3000B/H to 12000B/H.
Characteristic:
1. It carrys out bottle washing filling and capping in one machine.
2. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient.
3. It adopts bottleneck blocking type conveying-bottle structure to make changing bottle model more convenient, faster and easier.
4. The main machine adopts advanced PLC control technology. The key electric elements are adopting international famous products.
Technical parameter:
Model | DXGF14-12-5 | DXGF18-18-6 | DXGF24-24-8 | DXGF32-32-10 | DXGF40-40-12 |
Washing Heads | 14 | 18 | 24 | 32 | 40 |
Filling Heads | 12 | 18 | 24 | 32 | 40 |
Caping Heads | 5 | 6 | 8 | 10 | 12 |
Capacity(b/h) | 3000 | 4000 | 6000 | 8000 | 12000 |
Filling Precision | ≤+5mm | ≤+5mm | ≤+5mm | ≤+5mm | ≤+5mm |
Power(Kw) | 2.2 | 3.75 | 4.8 | 5.5 | 6.3 |
Wight Kg | 2500 | 3500 | 4800 | 5600 | 6500 |
Sizemm | 2250x1700x2300 | 2400x1960x2300 | 3010x2180x2400 | 4000x2250x2500 | 4200x3000x3150 |
