Home > Products > Carbonated drink filling line > cooling water tank and chiller
cooling water tank and chiller
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 per Month
- shanghai
- T/T
You May Like
-
Carbon dioxide purifier
-
mixing tank, juice mixing tank, sugar melting tank, heat preservation tank, storage tank
-
CIP cleaning system, clean machine, cleaning system, sterilizing machine, sterilization system
-
CIP automatic washing system, CIP, cleaning in site, CIP cleaning system
-
bottle drying machine, drying machine, bottle dryer, blow drying machine
-
bottle warming machine, beverage warming and sterilizing machine, bottle warming tunnel
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HFJX | |
| Model Number | LY series | Application | Refrigeration Parts | |
| Certification | CE |
Product Description
Specifications
It is used to cooling the water before mixing which is connected with the mixer..( carbonated drink macine)1. It is composed of water cooling tank and chiller; it is used in carbonated beverage line and sparking wine.(carbonated drink machine)
2. This product contains compressor using Freon F-12 or F22 as Refrigerant and pressure sensor and temperature regulator for automatic controlling.
3. It is used to cooling the water before mixing which is connected with the mixer.
Technical parameter:
Water tank model | LY-1200 | LY-2000 | LY-4000 |
Compressor | 2F6. 3-S | JZS-2F-10 | JZS-4F-10 |
Tank Volume (m3) | 1.2 | 2 | 4 |
Vapouning area (m2) | 7.2 | 11 | 20 |
Refrigerating capacity (W) | 5800 | 11000 | 22000 |
Water output (Kg/h) | 100-1,000 | 1000-2000 | 3000-4000 |
Water Temperature() | 0-5 | 0-5 | 0-5 |
Power (kw) | 6(double) | 1 1 | 2 2 |
Outline Size ( mm) | 1,200x1,000x2,100 | 2,200x1,200x1,800 | 2,200x1,250x1,800 |
Weight (kg) | 1,050 | 1,230 | 1,250 |
