Long Stroke Oilfield API B Series Pumping Units
- 500 Unit / Units per Month
- Tianjin
- T/T
You May Like
Product Details
| Condition | New | Production Capacity | 100% | |
| Place of Origin | Henan, China | Brand Name | Zhongshi | |
| Model Number | B | Voltage | 380V/220V | |
| Power(W) | Conventional | Dimension(L*W*H) | 10.58*2.74*10.15 | |
| Weight | 2-20 Tons | Features | API 11E Spe | |
| Certification | API 11E | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
API B series beam balance pumping unit is a kind of light-weight beam-pumping unit. It adopts beam balance and is widely used as ground power equipment in rod pumping work.
Brief Introduction :
API B series beam balance pumping unit is a kind of light-weight beam-pumping unit. It adopts beam balance and is widely used as ground power equipment in rod pumping work.
The products conform to API Spec. 11E “Specification for Pumping Units”, and the relative standards, acquired the authorization to use Official API Monogram.
Technical Performances :
1. Strength of critical parts is calculated with the finite element analysis,High reliability. simple operation, easy maintenance, long servicing life.
2. Gear reducer is involute herring-bone gearing, working smoothly and reliably.
3. Modularized design, it has high degree of standardization, commonality and seriation with the spare parts.
Item | Model | Rated Load | Stroke (in) | Gear Reducer Torque |
1 | B-80D-76-64 | 7,600 | 64,54,49 | 80,000 |
2 | B-80D-76-54 | 7,600 | 54,45,41 | 80,000 |
3 | B-80D-109-48 | 10,900 | 48,41,37 | 80,000 |
4 | B-80D-109-42 | 10,900 | 42,35,32 | 80,000 |
5 | B-57D-76-54 | 7,600 | 54,45,41 | 57,000 |
6 | B-57D-109-48 | 10,900 | 48,41,37 | 57,000 |
7 | B-57D-109-42 | 10,900 | 42,35,32 | 57,000 |
8 | B-40D-76-48 | 7,600 | 48,40,36 | 40,000 |
9 | B-40D-89-42 | 8,900 | 42,35,32 | 40,000 |
10 | B-40D-76-42 | 7,600 | 42,35,32 | 40,000 |
Restructured from SINOPEC in 1997, Puyang Zhongshi Group Co., Ltd has 18 years manufacturing experience of petroleum machinery products till now, we have competitive prices of our main products of casing accessories likebow spring centralizer, solid rigid centralizer,float equipment, cementing plug etc.
We have 9 factories, more than 500 employees, and many kinds of production equipments.
We have certificates of API 5CT,6A,10D,11AX,11E, ISO 14001 and 9001.
With 10 years exporting experience,we have exported to more than 30 countries such as America,Canada,Russia,Venezuela,Columbia,Thailand,Indonesia ,UAE,Saudi Arabia,Kazakhstan etc.
