Automatic Monitor Recycle Machine to Remove Screen for TV/computer

CRT is composed of funnel and panel, and there is a great difference of the compositions between them. Funnel

contains lead but most panels don’t. In order to recycle glasses in different kinds that the one with lead and the one

without must be separated from each other. The CRT cutting machine is a professional device for funnel and panel separation.

Ming-Xin CRT Monitor cutting machine is a mechanical cutting principle,automatic identification of CRT tubes of varying sizes, automatic cutting at its edges,can separate screen glass and glass cone effectively. The main feature is the cutting speed , stable performancr , automatic cutting process high degree of safety and reliability with a speed control device to control the cutting speed according to demand, with automatic dust removal device , comply with environmental requirements.

It’s mainly processed Size: 14 "to 33" TV waste, waste computer. (Excluding a liquid crystal display (LCD) , the processing time is about 30 seconds /pc.

Feutures :

• Separates CRT into funnel and panel
• Works on CRT from 14~33 inch
• Low power consumption, capacity is 80-120 units per hour
• Small in volume, low malfunction rate / maintenance cost
• Easy to operate with only one operator

Function Description :

Put the CRT which has been removed steel belt and electronic gun onto the work table of the separator. Operator

manually encircles the CRT with a heating wire, presses button to start cutting process, and then it will finish automatically.

After cutting process is done, takes the CRT to phosphor collecting table, removes metal plate, and then collects

phosphor. Also it can do the lead detecting as required.
