STA High alumina ceramic balls for ceramic grinding media
- shanghai qingdao
- T/T Credit Card
You May Like
-
STA High Alumina ceramic Ball with High Crush Strength
-
STA High density low abrasion rate alumina ceramic ball for grinding
-
STA High purity hot sale alumina ceramic balls
-
STA High purity 99% alumina ceramic balls
-
STA 17-99% al2o3 high grinding media alumina ceramic balls 0.5mm-70mm
-
STA Factory price 99.7% high purity alumina ceramic ball
Product Details
| Place of Origin | Henan, China | Type | Ceramic Balls | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | STA-CB001 | Brand Name | STA |
Product Description
Specifications
alumina ball:1. Al2O3: 17%~99.4%.
2. high crush strenghth, good impact resistance.
3. superior grinding efficiencies.
STA High alumina ceramic balls for ceramic grinding media
1.Product description
The 99% Al2O3 alumina ceramic ball are used as catalyst, absorbent, desiccant and drying agent in petroleum, chemical, fertilizer, natural gas and environmental protection industries. As a high alumina ceramic ball catalyst reactor coverage tower packing materials and support, the major role is to increase distribution of gas or liquid, support and protect the intensity of low strength activity catalyst.
2.Chemical composition of the high alumina ceramic ball:
Al2O3+SiO2 | Al2O3 | Fe2O3 | MgO | Na2O | Other |
> 99% | 99% | <0.1% | <0.5% | <0.05% | <0.05% |
3.Technical paremeter:
Product: Alumina Ceramic Ball | ||||||||||||
Category | Feldspar | Feldspar---- Mullite | Mullite | Mullite--- Corundum | Corundum | |||||||
Character |
|
|
|
|
| |||||||
Chemical Composition % | Al2O3 | 20-30 | 30-45 | 45-70 | 70-90 | ≥90 | ||||||
| Al2O3+SiO2 | ≥90 | ||||||||||
| Fe2O3 | ≤1 | ||||||||||
Water Absorption% | ≤5 | |||||||||||
Acid Resistance% | ≥98 | |||||||||||
Alkali Resistance% | ≥80 | ≥82 | ≥85 | ≥90 | ≥95 | |||||||
Temperature Resistance°C | ≥1300 | ≥1400 | ≥1500 | ≥1600 | ≥1700 | |||||||
Compressive
Strength
(N/Granule) | Φ3 | ≥130 | ≥140 | ≥150 | ≥160 | ≥200 | ||||||
| Φ6 | ≥400 | ≥420 | ≥440 | ≥480 | ≥500 | ||||||
| Φ8 | ≥480 | ≥520 | ≥600 | ≥620 | ≥650 | ||||||
| Φ10 | ≥600 | ≥700 | ≥800 | ≥900 | ≥1000 | ||||||
| Φ13 | ≥1000 | ≥1100 | ≥1300 | ≥1500 | ≥1800 | ||||||
| Φ16 | ≥1500 | ≥1600 | ≥1800 | ≥2300 | ≥2600 | ||||||
| Φ20 | ≥1800 | ≥2000 | ≥2300 | ≥2800 | ≥3200 | ||||||
| Φ25 | ≥2500 | ≥2800 | ≥3200 | ≥3600 | ≥4000 | ||||||
| Φ30 | ≥3000 | ≥3200 | ≥3500 | ≥4000 | ≥4500 | ||||||
Accumulation Weight(kg/m3) | 1300-1400 | 1400-1500 | 1500-1600 | 1600-1800 | ≥1800 | |||||||
Diameter(Φ) | 3,6,8,10,13,16,20,25,30,38,50,75 | |||||||||||
Remark | We also can produce the products as per your requirement. | |||||||||||
