C18150 copper bar used in welding for electrode caps and tips
- 500 Ton / Tons per Month
- shanghai qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | STA | |
| Model Number | STA-CB02 | Application | Air Condition Or Refrigerator, Water Tube, Water Heater etc... | |
| Diameter | 3mm~800mm | Shape | Round | |
| Length | 1-10 m | Cu (Min) | 90% | |
| Alloy Or Not | Is Alloy | Grade | C18150 |
Product Description
Specifications
C18150 copper bar/pipe/wire/rod1.Material designation:C18150,C18200,C18000,C15000
2.High electrical and thermal conductivity
Copper bar/pipe/wire /rod
1. Product details:
Chromium Zirconium Copper C18150 is an excellent and unique copper alloy with high electrical conductivity, hardness, and ductility, moderate strength, and excellent resistance to softening at elevated temperatures. The addition of 0.1% zirconium (Zr) and 1.0% chromium (Cr) to copper results in a heat treatable alloy which may be solution treated and subsequently aged to produce these desirable properties. Rod is usually supplied from the mill in the fully aged and drawn condition so no further heat treatment is required by the fabricator. The softening temperature of properly heat treated C18150 rod exceeds 500°C as compared to unalloyed pure copper which softens at 200°C, and silver bearing coppers which soften at 350°C.
2. Specifications:
Item | Copper bar ,copper rod ,Brass bar,brass rod |
Material | T1,T2,TP1,TP2,C10100,C10200,C10300,C10400,C10500,C10700,C10800, C10910,C10920, C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200, C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000,C27000, C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800,C63020, C65500,C68700,C70400,C70620,C71000,C71500,C71520,C71640,C72200,etc |
Standard | ASTMB152,B187,B133,B301,B196,B441,B465,JISH3250-2006,GB/T4423-2007,etc |
Diameter | 3mm~800mm |
Length | 5.8m,6m,or as required |
Surface | mill,polished,bright,hair line,brush,sand blast,etc |
Package | Standard export package,suit for all kinds of transport,or as required. |
Container Size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
Price term | Ex-Work,FOB,CNF,CFR,CIF,FCA,DDU,DDP,etc |
Payment Term | TT,L/C,Western Union,etc. |
MOQ | 100kg |
Application | Copper bar is widely used in boat building,War industry, Car industry and communication industry where the components need good wear proof and great corrosion resistance |
Contact | If you have any question,please feel free to contact me . We are sure your inquiry or requirements will get prompt attention. |
3.Advantages:
- Good wear resistance;
- High intensity;
- Hot Forging performance;
- Good cutting performance;
- Self-lubricating performance
- Copper bar can be made as all kinds of deep drawing and bending stress
- Copper bar has a good mechanical performance,under the hot plasticity is good,
corrosion resistance,is widely used an ordinary brass.
