Textile Braiding Machine DH100-40
- Shanghai
- T/T Credit Card
You May Like
-
Braiding Machine Price DH100-16
-
24 Spindle Middle Speed Fiberglass Rope Braiding Machine DH100-24
-
8 Spindle Middle Speed Fishing Line Braiding Machine DH100-8
-
48 Spindle Middle Speed High Tension Ropes Making Machine DH100-48
-
32 Spindle Sisal Rope Making Machine Machine DH100-32
-
Gift Bags Making Machine/ Hose Braider DH1O0-24
Product Details
| Place of Origin | Shanghai, China | Brand Name | Xianghai | |
| Model Number | DH100-40 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Application of braiding products:
High strength cables, fire ropes, mountaineering ropes, marine ropes, safety ropes, and etc..
Range of braiding materials:
All flexible fibers, yarns, belts, threads
Control system:
- Frequency inverter controlled production speed.
- Yarn broken sensor (if a yarn is broken or a bobbin is empty, the machine stops automatically)
- Speed set
- Control cabinet
Scope of supply:
- Machine with control system
- Operation and maintenance manual
- Tool box
- Wearing and sparing parts
- Training and trial operation
- Packing
Specifications
- Intelligent control system & advanced technology
- good quality & service and competitive price
- manufacturer & delivery on time
- CE,ISO9001
| DH100 Series Middle Speed Round Rope Braiding Machine | ||||
| Model | Spindle Qty | Measurement(mm) | Power (kw) | Bobbin Size(mm) |
| DH100-8 | 8 | 460 X 430 X 870 | 0.12 | Φ48 X 140/48 X 113 |
| DH100-16 | 16 | 540 X 460 X 900 | 0.12 | Φ48 X 140/48 X 113 |
| DH100-20 | 20 | 630 X 560 X 920 | 0.12 | Φ48 X 140/48 X 113 |
| DH100-24 | 24 | 680 X 590 X 950 | 0.18 | Φ48 X 140/48 X 113 |
| DH100-32 | 32 | 790 X 730 X 950 | 0.18 | Φ48 X 140/48 X 113 |
| DH100-40 | 40 | 1000 X 1000 X 1050 | 0.25 | Φ48 X 140/48 X 113 |
| DH100-48 | 48 | 1100 X 1100 X 1050 | 0.3 | Φ48 X 140/48 X 113 |
| DH100-56 | 56 | 1180 X 1180 X 1050 | 0.36 | Φ48 X 140/48 X 113 |
| DH100-64 | 64 | 1250 X 1250 X 1050 | 0.5 | Φ48 X 140/48 X 113 |
| DH100-72 | 72 | 1380 X 1380 X 1100 | 0.68 | Φ48 X 140/48 X 113 |
| DH100-84 | 84 | 1610 X 1600 X 1050 | 0.75 | Φ48 X 140/48 X 113 |
| DH100-88 | 88 | 1650 X 1650 X 1050 | 0.75 | Φ48 X 140/48 X 113 |
| DH100-96 | 96 | 1780 X 1780 X 2250 | 0.75 | Φ48 X 140/48 X 113 |
| DH100-104 | 104 | 1900 X 1900 X 2250 | 0.75 | Φ48 X 140/48 X 113 |
| DH100-108 | 108 | 1980 X 1980 X 2250 | 1.1 | Φ48 X 140/48 X 113 |
| DH100-120 | 120 | 2080 X 2080 X 2350 | 1.1 | Φ48 X 140/48 X 113 |
| DH100-140 | 140 | 2500 X 2500 X 2350 | 1.5 | Φ48 X 140/48 X 113 |
Range of products:
Gift bag ropes,high tension tension ropes,fishing lines,satety rope,fiberglass sleeves,round elastic bands,hollow ropes,core ropes,and etc.
Feature
1.There is a different kind of line according to the requirements of your product:
2. For the reduction of labor costs and increase production.
3. Machine long life, very durable
4. All the spare parts are made by ourselves, So we each production procedure of the control machine
samples:
